ZY8101 Series
Outdoor Led Tri Proof Light
IP Code: IP66
Ambient temp.: -40ºC to +50ºC
Application
It is an ideal lighting solution for the factory, station, tunnel, control room,
transformer room and some other indoor places with low bay roof.
Characteristics
1. With its reflector which have different angles design, it efficiently utilize the light. Have a good performance of illuminance uniformity, glare free, can avoid eyestrain to the worker.
2. It adopts American CREE LED as light source, can save 60% or more on energy than the metal halide lamp.
3. Efficient radiator effective solve the LED light failure caused by temperature rising, so as to ensure that LED life up to 100,000hrs.
4. Equipped with world top ranking brand, Taiwan Meanwell electrical appliance with power factor 0.98, make the lamp's performance more stable and efficient.
5. The locking device on the bracket will keep the lamp from shift or trembling during harsh vibration.
6. The housing adopts high-tech surface spraying technology, abrasion resistance corruption, waterproof, dustproof, suitable to be used in all kinds of environments.
7. 25W 40W with input voltage 18-43VAC / 18-55VDC is available.
Main parameter
| Input Voltage | 90-305VAC / 127-431VDC |
| Output Voltage | 42VDC |
| Frequency | 50Hz / 60Hz |
| Ingress Protection | IP66 |
| Anti Corrosion Grade | WF2 |
| Insulation Grade | I |
| Space Height Ratio | 4.5 |
| Leading-in cable diameter | Φ6mm -Φ8mm |
| Dimension | 300x300x75mm |
| Net Weight | 4.7Kg |
Ordering reference
| Model Number | Input Voltage | Light source | Rated wattage
Light source (W) | Light output
(lm) | Equivalent to |
| MH | LVD | CFL | HP |
| ZY8101-L25 | AC90-305V
or DC127-431V | LED | 25 | 3,300 | 70W | 60W | 80W | 80W |
| ZY8101-L40 | LED | 40 | 5,508 | 100W | 100W | 130W | 125W |
| ZY8101-L60 | LED | 60 | 8,138 | 150W | 135W | 180W | 175W |
| ZY8101-L80 | LED | 80 | 9,168 | 175W | 165W | / | 250W |
| Optional |
| ZY8101-L25-D | AC18-43V
or DC18-55V | LED | 25 | 3,300 | 70W | 60W | 80W | 80W |
| ZY8101-L40-D | LED | 40 | 5,508 | 100W | 100W | 130W | 125W |
Metal Halide Lamp: MH
Electrodeless Lamp: LVD
Energy Saving Lamp: CFL
High Pressure Mercury Lamp: HP
