Indoor Stairway LED Display Screen (P10)
| Price: |
Negotiable/Set |
| Trade Terms: |
FOB |
| Min Order: |
1/Set |
| Pay Type: |
T/T |
Stairway full color indoor LED display with SMD 3 in 1 technology is widely used in floor inside and outside.
With big viewing angle, uniformity brightness, high color saturation, and high definition, vivid, smooth result; It's very popular for T-show, bars, exhibition stand and so on.
|
ITEM |
PH10 |
|
Pixel Pitch(mm) |
10mm |
|
Constitution of Pixel |
1R1G1B |
|
Scan Mode |
1/8 |
|
Brightness (cd/m 2 ) |
> 1200cd |
|
Average Power (W/m 2 ) |
200W |
|
Max Power (W/m 2 ) |
500W |
|
Pixel of Module (dot) |
32× 16 |
|
Module Size(mm) |
320mm× 160mm |
|
Pixel Density (dots/m 2 ) |
10, 000dots |
|
Viewing Distance(m) |
8m-50m |
|
Weight (kg/m 2 ) |
45kg |
|
LED Drivemode |
Constant Current |
|
Gray scale |
12-16bit |
|
Refresh Rate |
1, 300-10, 000Hz |
|
Frame-changing Frequency |
More than 60Hz |
|
Display Interface |
VAG+DVI display card |
|
Display Mode |
1280*960 |
|
Control Mode |
Point to Point connect between LED display and Computer |
|
Transmission Distance |
CAT-5E≤ 130m/Multi-mode Optical Fiber≤ 500m / Single Mode Optical Fiber≤ 10km |
|
Video Acceptable |
TV, VCD, DVD |
|
Continuous Working Hours |
> 72 Hours |
|
Using Life |
100, 000 Hours |
|
MTBF |
> 10, 000 Hours |
|
IP Grade |
In-door IP43 |
|
Working Temperature |
-35to +60 |
|
Working Humidity |
Indoor 10to 60% |
| Prod Model: |
P10 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Pixel Configuration: |
1R,1G,1B |
| Pixel Pitch: |
10mm |
| Scanning Mode: |
1/8 Scan |
| Pixel Density: |
10,000 dots / m² |
| Display Function: |
Video Display |
| Tube Chip Color: |
Full Color |
| IP Rating: |
IP43 |
| System Operating Platform: |
WIN XP |
| Certification: |
CE |
| Application: |
Advertising |
