Indoor PH7.62mm Rental LED Display
Features:
1. Quick assmebly model, 2person are able to assmebly 20sqm within one hour
2. Light weight, for indoor application, only 38kg/sqm, for outdoor application, only 45kg/sqm
3. Weatherproof to IP65 standards
4. High resolution images
5. Easily configured for various size and aspect ratios
6. Wide viewing angle
7. Brightness from 6000 nits onwards
8. Compatible with inputs: S-Video, Composite, YUV, RBG, SDI, HKSDI, Data SVI up to SXGA
Indoor PH7.62mm Rental LED Display |
S/N | Module Specification |
1 | Pixel Pitch | 7.62mm |
2 | Pixel Configuration | 1R1G1B |
3 | LED Type | SMD 3IN1 |
4 | LED Wavelength | R(620-630nm) IV(150-200mcd) G(520-525nm) IV(260-330mcd) B(465-470nm) IV(55-65mcd) |
5 | Pixel Density | 17222 pixel dots/s.q.m |
6 | Module Size(W X H) | 244mm x 122mm |
7 | Module Resolution( W X H) | 32 pixel dots x 16 pixel dots |
8 | Input Voltage(DC) | 5V +/- 5% |
9 | Cabinet Specification |
10 | Cabinet Size(W X H) | 732mm x 732mm |
11 | Cabinet Resolution(W X H) | 96 pixel dots x 96 pixel dots |
12 | Unit Cabinet Weight | 13kg(without packaging) |
13 | Thickness | 70MM |
14 | Whole Screen Specification |
15 | Screen Brightness | Min. 2000nits/s.q.m |
16 | Driving Mode | Constant current 1/8 driving |
17 | H/V Visual Angle | 120 deg./55 deg. |
18 | Minimum Viewing Distance | 7.62m |
19 | Max. Power Consumption | 650W/s.q.m |
20 | Average Power Consumption | 500W/s.q.m |
21 | Gray Level | 4096 levels |
22 | Frame Frequency | Min. 60Hz |
23 | Refresh Frequency | Min. 400Hz |
24 | Blind Spot Rate | Max. 1/10000 |
25 | Protective Scale | IP20 |
26 | Screen Plainness | Max. +/- 1mm |
27 | Power Supply Mode | AC220 +/- 10% 50Hz/AC110 +/- 10% 60Hz |
28 | Environment Temperature & Humidity | Temperature -20 Celsius degree~+60 Celsius degree Humidity 10%~90% RH |
29 | Control System |
30 | Operating Environment | Operating system Chinese/English Windows98/me/2000/NT/XP
Hardware Configuration Pentium 300MHz or above ROM 64M Graphics Card Standard VGA 256mode or above
Related Software Microsoft Media player compulsory OFFICE2000 in case of *. doc files RealPlayer in case of RealPlayer files |
31 | Software | LED Studio |
32 | Control Mode | Synchronization display(work with computer) |
33 | Control System | DVI video card + full color control card + fiber system( optional) |
34 | Display Content | Video DVD, VCD, TV, image, texts.etc. |
35 | Interface | Standard Ethernet |
36 | Transmission Distance | CAT5 cable:<100 m; Single fiber:<10 km |
