Indoor P2.5 Full Color LED Screen Display

Product description:
The configuration of P2.5 indoor full color led display is 1R1G1B. The gap can be controled less than 02mm,cabinet installation just 20 seconds. Widely used in a variety of needs of large hall,sports arena,banking,telecommunications,govermentagencies,terminal,pier,railway stations,the stock market and other trading market,medical systems.electric power,galleries and other publicity,advertising,infomation dissemination,the guide places.

 Product Advantage:
1.Light, color can be customized.
2.Full magnesium desigh,cooling well,no fans,no noise.
3.High precision.
4.Fast disassembly module just 10seconds.
5.Convenient replacement and maintenance.
6.Durable cabinet structure.


Product Parameter

	Item	Parameter
Unit Module	Module size	240mm*120mm*10mm
	Module  thickness	10mm(without magnet)  13mm(with magnet
	Pixel pitch	2.5mm
	Pixel density	160000dots/m²
	Pixel configuration	1R1G1B
	Package mode	SMD2121
	Pixel resolution	96dots(W)*48dots(H)
	Max power consumption	20W
	Weight	0.21kg
	Drive type	constant drive
	Scan mode	1/24 scan
	Port type	HUB75E
	Brightness	≥1000cd/m²
	Dimension	480mm*480mm
	Quantity of module	8
	Power supply	5V/60A*1PCS
	Thermal discharge	fan 2pcs
	Pixel per cabinet	192mm*192mm
	Best viewing distance	2m~10m
	Best viewing angle	160°(W)120°(H)
	Temperature	working:-10ºC~+50ºC
	Relative humidity	20%~90%
Power	Working voltage	AC220V±10%
	Average power consumption	≤200W/m²
	Max power consumption	≤300W/m²
	Current	≤20mA(single LED)
Control system	CPU	pentium4 or above
	Operation system	WIN98/2000/NT/XP
	Control method	synchronization
Main technical parameter	Drving device	constant current drive IC
	Refresh frequency	≥400HZ
	Grey scale/color	256 levels of each color(RGB)/16.7M color
	MTBF	≥9000hours
	Power switch	automatic switch
	Display mode	800*600/1024*768
