HTS SMD LED DISPLAY FOR AV RENTAL USE
3.91mm pixel pitch, indoor die-casting aluminum slim led displays
P3.91
The premium 3.91mm die-casting LED display system for indoor use.
Fast & seamless assembly, superb image quality, wide viewing angles and unrivalled reliability.
Features:
1. Die-casting aluminum housing, rugged, good-looking. To ensure that the display of the seamless .
2. Super lightweight and thin, light-weight at 8.6kg/tile. Ultra-slim at 77mm depth.
3. Using E-energy universal voltage power supply, stable performance
4. Receiving card+HUB no flat cable. Stable performance, more reliable connections .;
5. No tools to assemble and dismantle, less worker and saves the cost
6. It suit for hanging-up, each hanging beam can bearing 10-15 pcs cabinets.
Application:
TV Show Ceremonies Shopping Mall
|
Specification |
|
LED |
|
|
Color |
Package |
Chip Brand |
View Angle |
Wavelength |
Test Cond. |
|
Red |
SMD2020 Black-face |
Epistar |
120°/120° |
625nm |
25 degree,20mA |
|
Green |
Silan |
120°/120° |
520nm |
25 degree,20mA |
|
Blue |
Silan |
120°/120° |
467nm |
25 degree,20mA |
|
Module |
|
|
Model No. |
HTS-P3.91 |
|
Pitch |
3.91mm |
|
Screen mode |
Real Pixel |
|
Physical density |
65536 Pixels per square meter |
|
LED type |
3-in-1 SMD2020 black-face |
|
Drive mode |
constant current |
|
Cabinet |
|
|
Resolution |
128x128pixels |
|
Width |
500mm |
|
Height |
500mm |
|
Depth |
60mm |
|
Weight |
8.6KG/cabinet |
|
Cabinet color |
Black |
|
Material |
Die-casting aluminum |
|
LED panel |
|
|
Brightness |
≥1400cd per square meter |
|
Flatness |
Gap≤0.5mm |
|
Gary scale |
65536 BIT |
|
Screen color |
281 trillion |
|
Scan method |
1/16 |
|
Operation power |
AC110V/220V, 50-60Hz |
|
Max power consumption |
250W/cabinet |
|
Ave power consumption |
120W/cabinet |
|
Control Mode |
Synchronous display with control PC by DVI |
|
Screen Refresh Frequency |
≥960Hz |
|
View angle |
Vertical: 120°, Horizontal: 120° |
|
Support Input |
composite, S-video, DVI,HDMI, SDI,HD-SDI,VGA |
|
Control Distance |
Ethernet cable≤120m or Fiber Optic>120m |
|
Brightness Correction |
pixel, module, cabinet |
|
Operating humidity |
10% - 80% RH |
|
Operating life |
100,000 hours |
|
MTBF |
5000 Hours |
|
Protection level |
IP40 front, IP20 rear |
|
Out of control rate |
0.02% |
