We can supply LED Display, LED Screen, LED Sign, LED Video Display, Full color indoor LED display, Full color outdoor LED dislay. LED Panel, LED billboard, LED advertising display, LED display board, LED display module.
(1) "SMD 3 in 1" is a kind of techniques for Indoor full-color LED display. Our LED Screen allows a side viewing of up to 140 degrees, which guarantees perfect images to every member of your audience.
(2) We control the dead pixel rate within 1/100, 000 per year. The LED display is uniformity in color and brightness, in avoid "splash", " glare" "mosaic" and "blur".
(3) Multiplied file formats, such as AVI, MOV, MPG, DAT, VOB are comprehensive, and we have three display mode as VGA+VIDE and VGA. There are also interfaces for Sound signal and video signal.
(4) 65536 display colors(16bit) control system and the color is over 281 trillions, the refresh rate can be up to 9000Hz, and the brightness, contrast, saturation, chroma can be adjusted by manual and sensor.
(5) Show all kinds of word, text, graph, picture, video, 2-dimention, 3-dimention cartoon and other information with your PC does synchronously.
(6) Can be connected with PC and the web net and show the content, and also can be controlled remotely via VPM+ADSL.
Specification |
Parameter |
Pixel Pitch |
10 mm |
Pixel composing |
SMD 3 in 1 |
Density per sqm |
10000 pixel |
LED package |
SMD3528 |
Module size |
160mm*160 mm |
Display resolution/module |
16 dots*16 dots |
Standard cabinet size |
1120*960 mm /960*960mm |
Weight per sqm |
48 Kg/sqm |
Wave Angle (H) |
140° (H)/ 140° |
Display color |
65536*65536*65536 (16bit) |
Whiteness brightness |
≥ 1500 |
Changing frame frequency |
60 Hz |
Refresh |
1400 Hz |
Driving method |
1/4 Constant Driving |
Control way |
Real Pixel |
Max power/sqm |
625W/sqm |
Average power/sqm |
337W/sqm |
Working voltage |
AC 220± 10%50Hz or AC 110± 10%60Hz |
Short circuit protection |
Yes |
Working temperature |
-5~50 centigrade |
Working Humidity |
10~90% |
Out of control |
1/10, 000 ( scattered) |
Lifetime |
100, 000 hours |
Environment |
Indoor |
Install mode |
Wallmount |
Control mode |
Synchronous |
Display port |
DVI |
Display mode |
1024*768 /1024*1024 |
Shenzhen Tricolor Technology co., Ltd. is an integrated service supplier, which is specializing in the R&D, production and market of LED display screen. We specialize in one-stop service on solution offer, design, product manufacture, installation and after sale service that satisfy customer on various demands. Now Tricolor covers the solutions with LED Curtain Solution, Rental LED Screen Solution, Permanent Installation LED Screen Solution, Perimeter LED Screen Solution. We do our best to serve quality market customer all the time.
Tricolor is founded by a team with skilled and experienced technicians, who will dedicate themselves to research and provide complete LED display system solution; Tricolor promotes the environment protection and energy saving with technology. We would like to offer the most reasonable solution for the users by all-dimensional technology integration of electronics, optics, structure, system performance, and easy operation and product reliability.
Tricolor consider product quality as company life, we take serial reliable tests in each process from the initial production until finished product. The tests cover all important performances, including flatness, power consumption, brightness, color, shock resistance; IP rating and so on, we will adopt the most strict quality control system to guarantee products with best quality.
