Application
It is an ideal lighting solution for the factory, station, tunnel, control room, transformer room and some other indoor places with low bay roof.
Characteristics
1) The unit efficiently utilize the light, utilization rate can reach 97%. Besides, it has a good performance of illuminance uniformity, glare free, can avoid eyestrain to the worker.
2) Vane type structure housing accelerate the heat dissipation, so that to ensure the LED service life.
3) It adopts American CREE LED as light source, can save 60% or more on energy than the metal halide lamp
4) Equipped world top ranking brand electrical appliance, make the lamp's performance more stable and efficient.
5) The unit have excellent electromagnetic compatibility, will not cause interference to the other device or the electric power transmission network.
6) The anti corrosion, abrasion proof, power coated cover which is dust proof, water proof , make the lamp an excellent option for all kinds of high stress environment.
Date Sheet
Input Voltage |
AC90~264V |
Output Voltage |
DC18~28V |
Frequency |
47~63Hz |
Anti Corrosion Grade |
WF2 |
Insulation Grade |
I |
Spacing Height Ratio |
2 |
Leading-in Cable |
Φ6mm~Φ8mm |
Size |
Φ240×65mm |
Net Weight |
1.4kg |
Model No. |
Light Source |
Rated Wattage (W) |
luminous flux (Lm) |
Light average life (h) |
ZY5301-L10 |
LED |
10 |
1356 |
100,000 |
ZY5301-L25 |
LED |
25 |
3300 |
100,000 |
ZY8301-L40 |
LED |
40 |
4890 |
100,000
|
