18/20/20 controlling channels
OSR HTI1500W/S lamp, parabolic glass reflector
Liquid-crystal display in Chinese, English and French can visually set customized function. Adopt "One button" roller design to operate menu, longer service life. Inside chargeable battery, DMX address and other feature index can be set when power off
CMY stepless color mixing system
Linear color temperature correction (3000K-6000K)
Color wheel(optional): Two color wheel, each wheel has 4 color plus write color with rainbow effect, interchangeable, dual-direction rotation, Various colors can be chosen by lighting designer, creates perfect lighting effect
2 soft light filters
Independent strobe and shutter device, ideal dimmer and strobe effect
Electric lighter
0-100% mechanical dimmer with strobe as 1-13 flash per second
Electric linear focusing 11° -57°
540° Pan with 8 or 16 bit resolution
252° Tilt with 8 or 16 bit resolution
Automatic Pan and Tilt repositioning by photoelectric repositioning system if accidentally knocked out of place
Combine standard DMX512 protocol, Art-net ether light control protocol and wireless DMX512 communication
Superheat protection
Silence operation: The noise is lower than 40dB within 1meter
Voltage: AC 100v-130v/200v-250v, 50-60Hz
Power: 1750w
AC/DC Switching power supply, wide range working voltage, not affected by voltage/frequency fluctuation from different regions, improve fixture's working stability
Electronic ballast with APFC power factor correction function, power factor is 0.99, THD<20%, power utilization efficiency is 20% higher than common fixture
Intelligent power-saved system can reduce light source power, when the dimmer is off, has the saving power function, or all the CMY filters shuttered, the lamp consumption can be reduced by 50% automatically
Size: 485mmX460mmX740mm
N. W.: 32KG.
Up to CE standard and GB7000.15-2000 standard
Guangzhou ChaiYi Light Co., Ltd is as one of the leading stage light manufacturer in the world. Our main products include Moving head, Outdoor, LED, scanner, flow spot, etc. Especially professional in moving head light.
We offer a complete customer service: Easy-to-place orders; Quick quotes and speedy production, high quality and high fidelity function; On-time after sales service. Many parts for our products are imported from Europe and USA, such as CMY system, ballast, optical system and so on. Our quality can compare with the European products but our prices are also more competitive
