GC-103W
Electrode less Induction High Bay Light
Applied range: Various power distribution room, main building, pump room, boiler room, lounge, trestte, within the coal bunker place fixed lighting lamp
Application: Indoor, outdoor
Enclosures: Die-casted with aluminum alloy without copper, shot blasting Cleaning, electrostatic polyester-sprayed
Exposed fastener: High quality stainless steel
Display: Impact-resistant and hermally stable toughened glass
Component: Electrode less lamp, the average life expectancy of 80 thousands to 80 thousands hours, high power factor, high efficiency and energy saving can be > 0.99, instantaneous starting, no flashing
Structure description: Silicone rubber gaskets structure design with strong protection
Installation: Ceiling mounting(X), pole mounting(g), wall mounting(b), fence mounting(h), flange mounting(f)
Implementation of standards: GB7000.1\GB700.201; IEC60598-1\IEC60598-2-1
Degree of protection: IP65
Rated voltage: AC220V/50Hz
Light source power: 40W, 50W
Corrosion-proof: WF1*WF2
Thread of inlet: G3/4"
Cable diameter: Φ10mm-Φ14mm
Light source type: Annular electrode less induction lamp(ED)
