Led light manufacturers and factory

Home LED Light Products Eastar Staper Series P12mm Outdoor Sport LED Message Board Display

Eastar Staper Series P12mm Outdoor Sport LED Message Board Display

Eastar Staper Series P12mm Outdoor Sport LED Message Board Display
Price: US $ 1USD
Trade Terms: FOB,CIF,others
Min Order: 1/Square Meter
Pay Type: L/C,T/T,Western Union
Eastar staper series P12mm outdoor Sport LED message board display:
* Stable LED message board display technology and Hight Reliability.
* LED message board with Low power consumption.
* Weather resistant cabinet.
* Modular construction for flexible sizes.
* Video, graphics & animations.
* Automatic brightness control.
* High brightness and better contrast.
* Supports multiple input formats.
Item Parameters
MODULES model ESD-OE12S
Pixel Pitch(MM) 12
Physical Density(dot/M2) 6, 944
LED Arrangment 1R1G1B
LED Type SDM3535
Module Size(MM*MM) 192*192
Module Resolution(PX*PX) 16*16
Module Power Comsumption(W) 40
main technical parameters Drive Mode Constant Current Drive
Scan Mode  1/2
Horizontal Viewing Angle(Deg) 140
Vertical Viewing Angle(Deg) 140
Brightness(CD/M2) 4000
Grey Scale > 4096
Refresh Rate(HZ) 4800
Cabinet Resolution 112*80
Cabinet Max Power Consumption(W) 1500
Cabinet Average Power Consumption(W) 600
Cabinet Size(MM*MM) 1344*960
Cabinet Weight(KG) 80
Cabinet Thickness(MM) 150
Cabinet Material ALU/Steel
Color(M) > 16.7
Input Voltage AC 110V~220V+/-10%
Refresh Frame Frequency(Hz) 60
Protection Level IP65
Working Environment Outdoor
Working Temperature(Celsius degree) -20~+40
Storage Temperature(RH) 10%-90%
Life Span(H) 100, 000
Prod Model: ESD-OE12S
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Pixel Configuration: 1R, 1G, 1B
Pixel Pitch: 12mm
IP Rating: IP65
Tube Chip Color: Full Color
Display Function: Advertising,Video,Flash,Picture etc
Certification: CE,FCC,RoHS,UL,ETL
Shenzhen Eastar Electronic Co., Ltd., is an integrated service supplier of LED display screens headquartered in the city of Shenzhen, China.After six years professional experience in LED R&D significantly guarantees high quality of the products which have been exported to more than 80 countries and regions in the world, such as USA, UK, Italy, Belgium, etc.Our effective management and prompt and creative services have won a good reputation from our customers from all over the world.

Our manufacturing center is equipped with world class manufacturing equipment.Now, there are 3 YAMAHA SMT high speed mounters, 2 auto colorgraph and beam splitting machines, backflow welding machines, wave crest welding machines, and supersonic wave cleaning machines.We take advertage of the latest technology to meet the ever-demanding needs of the market.So All above these machines is operated automatically, promote our efficiency and ensure our products high quality.

EASTAR strictly implements the 5S production management system and ISO2001 Quality Control System.Up to now, we have the UL, CE, RoHS, etc certificatios.Meanwhile, we are on the way of applying new quality control certifications and keeping the principle 'customers and Quality come first' in our mind to make sure everystep operated normally and eliminate the mistake at the first time.

Come and talk to one of our representatives, whether you are interested in buying a LED display screen, or you are looking for a good supplier to work with in your market.We are willing to share our experience with you and we will also share with you the satisfcation brought by a good piece of product, or the success brought by our faithful cooperation!So welcome to join us!
