Home LED Light Products Curtain Strip P25 Outdoor Fullcolor Advertising Rental LED Scrolling Display

Curtain Strip P25 Outdoor Fullcolor Advertising Rental LED Scrolling Display

Curtain Strip P25 Outdoor Fullcolor Advertising Rental LED Scrolling Display
Price: US $ 1USD
Trade Terms: FOB,CIF,others
Min Order: 1/Square Meter
Pay Type: L/C,T/T,Western Union
Strip Series Features

Synchronous adjustment of the color and brightness let the screen present an exquisite realistic color performance

Compatible with a variety of signal input, such as AV, S-Video, DVI, VGA, YPbPr, HDMI, SDI, DP and so on.

Professional packaging protection with flight case played a good protective effect on the cabinet.

The screen design is Lightweight and ultra-thin.

The new retractable lifting structure, quick to install, easy to maintain.

Fast lock installation design make it convenient to dismantle and install.

Small power consumption.
  Item Parameters
MODULES model ESD-CS25S
Pixel Pitch(MM) 25
Physical Density(dot/M2) 1, 600
LED Arrangment 1R1G1B
LED Type SMD5050
Module Size(MM*MM) 11*600
Module Resolution(PX*PX) 1*24
Module Power Comsumption(W) 8
main technical parameters Drive Mode Constant Current Drive
Scan Mode  Static
Horizontal Viewing Angle(Deg) 140
Vertical Viewing Angle(Deg) 140
Brightness(CD/M2) 2500
Grey Scale > 4096
Refresh Rate(HZ) > 1800
Cabinet Resolution 24*24
Cabinet Max Power Consumption(W) 200
Cabinet Average Power Consumption(W) 80
Cabinet Size(MM*MM) 600*600
Cabinet Weight(KG) 7
Cabinet Thickness(MM) 79
Cabinet Material ALU
Color(M) > 16.7
Input Voltage AC 110V~220V+/-10%
Refresh Frame Frequency(Hz) 60
Protection Level IP65
Working Environment Outdoor
Working Temperature(Celsius degree) -20~+40
Storage Temperature(RH) 10%-90%
Life Span(H) 100000
Vertical Hanging Quantity 20
  Item
Parameters
MODULES model ESD-CS25S
Pixel Pitch(MM) 25
Physical Density(dot/M2) 1, 600
LED Arrangment 1R1G1B
LED Type SMD5050
Module Size(MM*MM) 11*600
Module Resolution(PX*PX) 1*24
Module Power Comsumption(W) 8
main technical parameters Drive Mode Constant Current Drive
Scan Mode   S tatic
Horizontal Viewing Angle(Deg) 140
Vertical Viewing Angle(Deg) 140
Brightness(CD/M2) 2500
Grey Scale > 4096
Refresh Rate(HZ) > 1800
Cabinet Resolution 2 4*24
Cabinet Max Power Consumption(W) 200
Cabinet Average Power Consumption(W) 80
Cabinet Size(MM*MM) 6 00*600
Cabinet Weight(KG) 7
Cabinet Thickness(MM) 79
Cabinet Material A LU
Color(M) > 16.7
Input Voltage AC 110V~220V+/-10%
Refresh Frame Frequency(Hz) 60
Protection Level IP65
Working Environment O utdoor
Working Temperature(Celsius degree) - 20~+40
Storage Temperature(RH) 1 0%-90%
Life Span(H) 100000
Vertical Hanging Quantity 20
Prod Model: ESD-CS25S
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
LED Density: 1600dots/Sqm
LED Configuration: 1r1g1b
Brightness: 2500dots/Sqm
Hor. Viewing Angle: 140deg
Vert. Viewing Angle: 140deg
Pixel Configuration: 1R, 1G, 1B
Pixel Pitch: 25mm
IP Rating: IP65
Tube Chip Color: Full Color
Pixel Density: 1600
Display Function: Advertising, Video, Picture, Flash etc
Average Power Consumption: 80
Certification: CE, FCC, RoHS, UL, ETL
Shenzhen Eastar Electronic Co., Ltd., is an integrated service supplier of LED display screens headquartered in the city of Shenzhen, China.After six years professional experience in LED R&D significantly guarantees high quality of the products which have been exported to more than 80 countries and regions in the world, such as USA, UK, Italy, Belgium, etc.Our effective management and prompt and creative services have won a good reputation from our customers from all over the world.

Our manufacturing center is equipped with world class manufacturing equipment.Now, there are 3 YAMAHA SMT high speed mounters, 2 auto colorgraph and beam splitting machines, backflow welding machines, wave crest welding machines, and supersonic wave cleaning machines.We take advertage of the latest technology to meet the ever-demanding needs of the market.So All above these machines is operated automatically, promote our efficiency and ensure our products high quality.

EASTAR strictly implements the 5S production management system and ISO2001 Quality Control System.Up to now, we have the UL, CE, RoHS, etc certificatios.Meanwhile, we are on the way of applying new quality control certifications and keeping the principle 'customers and Quality come first' in our mind to make sure everystep operated normally and eliminate the mistake at the first time.

Come and talk to one of our representatives, whether you are interested in buying a LED display screen, or you are looking for a good supplier to work with in your market.We are willing to share our experience with you and we will also share with you the satisfcation brought by a good piece of product, or the success brought by our faithful cooperation!So welcome to join us!
