Applican
This product is widely used in the factory , various city road , high ways as street light
Characteristic of profermances
1)The housing is specially designed for the heat dissipation. It effectively solved the LED degradation problem caused by the high temperature during use. So that the unit ensured the light efficacy and the 100,000 hours service life.
2)The even light distribution can avoid the shadow area between the two streetlights. It is glare free. And has a pure white light.
3)It adopts American CREE LED as light source, can save 60% or more on energy than the metal halide lamp.
4)Equipped world top ranking brand, Taiwan Meanwell electrical appliance with power factor 0.98, make the lamp's performance more stable and efficient.
5)Easy maintenance
6)The shell adopts high-tech surface spraying technology, abrasion resistance and resistance to corrosion, waterproof, dustproof, applicable to all kinds of environments
7)Mounting: suitable to pole with the diameter of 55-60mm
Order reference
| Input voltage | AC90~305V |
| Out voltage | DC27~54V |
| Frequency | 47~63Hz |
| Anti corrosion grade | WF2 |
| Insulation Grade | I |
| High space ratio | 3 |
| size | 640×320×72.5mm |
| Net weight | 7kg |
| Model No. | Light source | Ratedpower
(w) | luminous flux
(Lm) | Equivalent to |
| Metal Halide Lamp | High Pressure Mercury Lamp | Electroless Lamp |
| ZY8701-L50 | LED | 50 | 5584 | 100W | 70W | 100W |
| ZY8701-L60 | LED | 60 | 7225 | 150W | 100W | 135W |
| ZY8701-L80 | LED | 80 | 10016 | 175W | 150W | 165W |
| ZY8701-L100 | LED | 100 | 11568 | 250W | 175W | 200W |
| ZY8701-L120 | LED | 120 | 12640 | 250~400W | 250W | 250W |
Zhejiang Tormin Electrical Co., Ltd. is a high-tech civilian enterprise that specializes in r & d, manufacture and sales of industrial illumination lamps. Its products are widely used in the fields of electric power, coal mine, petrol, chemical, metallurgy, railway, large airport, fire-fighting, military, flood prevention, rescue work and disaster relief.
In light of the world wide advocating of low carbon economy, zhejiang tormin electrical Co., Ltd. Will carry on the mission of low-carbon illumination, energy conservation & emission reduction, and strive to create a first class brand for industrial lighting in China with the operation guidelines of energy conservation, environmental protection, pragmaticness and innovation. We are always committed to the r & d of a new generation of low energy consumption illumination products and the supply of green products for customers. In an era of low carbon illumination, the company deems the energy-favored illumination as a major project, makes use of the latest technology through independent r & d and technical exchanges and cooperations with counterparts from both at home and abroad, and develops a series of high efficiency products with the combination of efficient illumination sources and electric appliances, whose energy saving effects have reached the internationally advanced level, thus making due contributions for the energy conservation and emission reduction.
The company boasts powerful r & d and manufacturing capabilities, being one of the largest industrial illumination r & d and production bases in China. It is awarded as the technology-oriented small and medium-sized enterprise in zhejiang province, patent demonstration enterprise in wenzhou city, and key patent protection enterprise, etc. At the same time, tongming has obtained the certification of ISO9001: 2008 international quality management system, the national coal mine safety, the state luminaire quality supervision and inspection center, the state fire-fighting equipments quality supervision and inspection center, CE&RoHS, ATEX, IECex and other authorities.
The company enjoys very rich experiences in the planning and implementation of energy conservation projects in various plants, and has developed a number of energy-friendly illumination solutions geared to various industries in China. It provides a whole set of technical services for enterprises in the areas of electric power, metallurgy, petrochemical and coal mine, from the support of energy conservation plans, product selection, project installation, to after-sales services.
With the determination of contributing to the nation and shaping a centennial brand, and upholding the tenet of win-win among customers, employees and the company, zhejiang tongming electric appliance Co., Ltd is endeavoring to create an excellent platform for more and more elites who are to join tongming, and commonly establish a first class illumination enterprise.
