Cheap price outdoor full color led display screen // display led billboard // led screen display //
Product features
1. New look, new vision, it is very like flat-panel TV in the shape and it has powerful capabilities of multimedia playback.
2. Its viewing distance is 2m-50m, far ahead of the flat-panel TV.
3. 16:9 standard theater mode display size without distorting, not tear fully retain the highest quality of the video screen
4. There are fans that in the display, which makes the display work safely.
5. We adopt the All-digital stamping technology and make the display body as slim as 76mm.
6. We offer 500MB Mass storage, which will make you program more wonderful.
7. We provide kinds of software and it will be easy to learn and use, anyone can handle it easily.
8. We put a automatic environment sensing device in the display, it will adjust the brightness of the display Automatically and can display the temperature and humidity.
9. Its brightness is more than 2000cmd which is 6.6 times that of the flat-panel TV. It will not be affected by the environment brightness easily, which makes the screen more beautiful.
10. 4096 gray HD smooth video playback, Stunning visual experience.
11. It will full support for the various forms of video, animation, text and tables.
12. It can display the digital clock.
13. There are 3G wireless modules in it, which makes the data transmission more fast.
14. We use the wireless remote to control it, which makes it easy for us to change the channels.
15. We put 2mm thickness of ultra-thin tempered glass in the surface of it, which protect it from the rain and dust.
16. You can choose the installation as you like, wall-mounted or column.
17. We adopt the new design, in front of it was a panel, the middle is the cabinet and the back is a panel too, which makes it easy for us to assemble.
18. Aviation-style power plug, unique protection design make it more safe while using.
19. We adopt the U disk to transmit the information and it won't be limited by the internet.
20. Built-in USB integrated sound and stereo surround sound box makes the screen waving with the sound.
parameters of p4 |
|
| no | item | parameter |
| pixel |
| 1 | pixel pitch | 4mm |
| 2 | resolution | 224x128 |
| 3 | horizontal axis | 160° |
| 4 | vertical axis | 160° |
| 5 | pixelcomposition | 1R1G1B |
| 6 | led pixel type | SMD 2020 |
| 7 | white brightness | 2000-2500cd/m |
| 8 | white balance coordinates | x=0.29,y=0.31 |
| 9 | color temperature | 8000k |
| 10 | contrast | 64000:1 |
| 11 | gray scale/color | 16.7M |
| 12 | refresh rate | 480HZ |
| 13 | viewing distance | 2-50M |
| Module |
|
| 1 | resolition | 32x32 |
| 2 | dimension | 128mmx128mm |
| 3 | type | Synergetic lamp and drive |
| 4 | scan method | 1/8 Scan |
| 5 | drive method | Constant current |
| 6 | working voltage | 5v |
| 7 | maximum consumption | 25W |
| 8 | average consumption | 6.25W |
| 9 | shell material | PC |
| 10 | mask material | PC |
| apperance of size |
|
| 1 | displaying size | 896mmx512mm |
| 2 | cabinet dimension | 1188x602x76mm |
| 3 | cabinet material | aluminum alloy |
| 4 | cabinet color | black |
| 5 | supporting brachet size | 1298mmx802mm |
| 6 | supporting brachet material | iron |
| power supply |
|
| 1 | input voltage | 100v/AV |
| 2 | input rate | 50-60HZ |
| 3 | maximum consumption | 420w |
| 4 | average consumption | 105w |
| application environment |
|
| 1 | application environment | indoor/outdoor |
| 2 | working temperature |
|
| 3 | working humitidy | 10%-90% |
| 4 | stock humitidy |
|
| 5 | protection grade | the front face IP65 ,the back face IP43 |
| function |
|
| 1 | controle method | asynchronous display |
| 2 | Built-in capacity | 500MB |
| 3 | U disk play | 8GB(maximum |
| 4 | Broadcast regularly | support |
| 5 | Brightness adjustment | auto/6 levelsoftware |
| 6 | Temperature and humidity display | support |
| 7 | Infrared remote control switch programs | support |
| 8 | Video format | supportAVI,WMV ,MPG,MOV,DAT,VOB,MP4,FLV |
| 9 | Animation format | GIF,SWF |
| 10 | picture format | SUPPORT BMP.JPG,GIP,WMF,ICO |
| 11 | text | TXT,RTF,single text,static text and Multiple lines of text |
| 12 | form | support |
| 13 | time | suport digital clock display |
| 14 | partition display | any |
| 15 | MTBF | ≥10000 hours |
| 16 | Longevity | ≥10000 hours |
| sound |
|
| Built-in speakers | support |
| Channel | double channel |
| Volume | 85db |
| power | 1.2wx2 |
| Frequency Response | 200hz-18hz |
| Sensitivity | 800db/1w/0.5m |
| operating system |
|
| operating system | windows7,xp |
| software | led editor |
Located in Baoan District, Shenzhen Myled Optech is an professional LED display manufacturer which is dedicated to LED display R&D; Production, sales, marketing and one stop solution for customers mainland and international. Myled provides consulting, installation, training and sales services for customers. We always regard customers as the company life line.
Shenzhen Myled Optech focus on indoor and outdoor full color LED display, LED curtain display, mesh, indoor and outdoor single and bicolor LED display manufacturing. We have established business relationship with customers in South America, Euro, and Asia etc. And win a good reputation among customers all over the world. And we provide full solution for Government, Telecom, Hotel, airport, bus station, stadium, and cinema and financial center, etc. Over the past years, we have finished some important LED display project for South American and China Mainland.
Quality is the most important theme for Myled and welcome to contact, and visit our company.
We hold the truth that better quality, better price and better sales services are our company culture.
