260W beam moving head light(Moore 260)
Technical Parameter
Voltage: 100V~240V 50/60Hz
Ballast: Electronic ballast
Lamp: 260W
Color Temperature: 8500K
Average lifespan: 2000H
Color: 14 colors + empty
Gobos: 17 fixed gobos + empty
Prism: 8-facet prism, bidirectionally rotation.
Beam effect can be opened and shuttered.
Frost effect: Adjustable spot angle for frost.
Iris: 7 Grades Adjustor for Beam shot.
Focus: Linear focusing
Dimming: 0+-100% linear adjustment
Range: Pan 540° , Tilt 260°
16Bit control mode.
Auto re-positioning function.
Strobe: 0.5-12 times/second
Control mode: DMX 512
Channels: 16/20 channels
Other functions: LCD Display panel, Chinese and English Display.
Remote control on/off for lamp.
Power saving mode: Timer for recording fixture and lamp using status.
Body housing material: Plastic and alloy
IP Grade: IP20
NW. 17.5KGs.
|
DMX Channels(Standard Mode) |
|
|
CH1 |
COLOUR WHEEL |
|
CH2 |
STROBE |
|
CH3 |
DIMMER |
|
CH4 |
STATIC GOBO |
|
CH5 |
PRISM INSERTION |
|
CH6 |
PRISM ROTATION |
|
CH7 |
EFFECTS MOVEMENT |
|
CH8 |
FROST |
|
CH9 |
FOCUS |
|
CH10 |
PAN |
|
CH11 |
PAN FINE |
|
CH12 |
TILT |
|
CH13 |
TILT FINE |
|
CH14 |
FUNCTION |
|
CH15 |
RESET |
|
CH16 |
LAMP CONTROL |
