Model: KL4Ex
ATEX No.: Baseefa09ATEX0205-Issue 2
Specification:
Rated voltage .......................................... 3.7 V
Rated capacity ........................................ 4 Ah Li-ion
Lighting time ........................................... >15 hours
Explosion protection type ........................ Ex ia I
Maximum Illumination 1m from lamp:
Beginning of lighting ............................... >3500 lux
After 11 hours lighting ............................. >3000 lux
Main Light current ................................... 0.22A
Sub-light current .................................... 0.06 A
Battery life .............................................. 2 years
Charging time ......................................... <8 hours
Charging voltage ..................................... 6-8 V
Ingress protection ................................... IP65
Weight ................................................... 600g
Exterior dimensions ................................ 120x130x105mm
Standard:
The miner's cap lamp complies with the following Standards:
-EN 60079-0: 2012
-EN 60079-11: 2012
-EN 62013-1:2011
-EN 50303:2000
Features:
-Li-ion batteries and LED light source
-Short Circuit Protection, Over-Current Protection
-Electronic switch controls the ON/OFF of the main/auxiliary light sources
-A charging control circuit is fitted inside the headpiece of the lamp,enables
the lamp can be charged by other manufacturer's chargers
-LED light source can be replaced before the battery life is exhausted
-Compact, light weight, maintenance free,long life span, intrinsically safe
We're a ISO9001: 2008 Certified company that develop and manufacture coal mining safety equipment with the brand name of "GOKANG" since 1995. There are more than 50 skill engineers and 100 workes. Our factory locete in Xi'an China.
Cap lamps KL1.2Ex, KL4Ex, KL6Ex have passed ATEX/CE certification, Self rescuer K-S60 got CE(EN 13794) mark. They have been export to Chile, Brazil, Colombia, Mexico, America, United Kingdom, Swedden, Spain, Turkey, Russia, Ukraine, Kazakhstan, Romania, Iran, Tanzania, Georgia, Zimbabwe, India, Philippines, Vietnam, Australian, etc.
Welcome to Shaanxi Star Coal Mine Safety Equipment Co., Ltd.
Main Products:
1. Mining cap lamp
2. Mining self rescuer
3. Mining gas detector&sensor
