7pcs RGBW Mini led wash Moving Head disco light
Disco lighting,DJ lighting 7X10W LED moving head light RGBW 4 IN 1 with zoom for night club, party
Specifications:
Input volt: | AC100-240V 50/60Hz |
Power: | 84W |
LED: | 7X10W CREE LED |
Luminous flux: | 3500LM |
Lifetime: | 50000 hours |
Pan: | 540° 8/16bit |
Tilt: | 270° 8/16bit |
Beam angle: | 8-60° |
dimming: | 0-100% |
strobe: | 0-25times/s |
Dispaly: | LCD screen |
Signal interface: | 3-PIN/5-PIN XLR interface |
Power interface: | 3-PIN |
Control: | DMX512/ Sound,Auto,Master-slave |
Channel: | 16 Channel |
Heat Sinking: | air cooling system |
Housing material: | with aluminum alloy inside and Die casting plastic |
Size: | 27 X 36 X 39CM |
5.05KG/11.1lbs: | 5.05KG/11.1lbs |
Gross Weight | 5.84kgs/12.9lbs |
Packing Dimensions | 300X270X440mm/Single ctn 470X430X350cm/Dual ctn |
DMX Chanel :
Channel | Value | Value | Function |
| Standard | Sample | |
1 | 0-255 | 0-255 | X axis |
2 | 0-255 | 0-255 | Y axis |
3 | 0-255 | 0-255 | F motor |
4 | 0-255 | 0-255 | general dimmer |
5 | 0-255 | 0-255 | Red |
6 | 0-255 | 0-255 | Green |
7 | 0-255 | 0-255 | Blue |
8 | 0-255 | 0-255 | White |
9 | 0-2 | | no choosing colour or self-define colour |
3-255 | | self-define colour(self-define on) |
3~20 | | R255 G↑ B0 W0 |
21~40 | | R↓ G255 B0 W0 |
41~60 | | R0 G255 B↑ W0 |
61-80 | | R0 G↓ B255 W0 |
81-100 | | R↑ G0 B255 W0 |
101-120 | | R255 G0 B↓ W0 |
121-140 | | R255 G↑ B↑ W0 |
141-160 | | R↓ G↓ B255 W0 |
161-170 | | R255 G255 B255 W255 |
171-200 | | R0 G0 B0 W0 |
201-205 | | R242 G204 B5 W227 |
206-210 | | R242 G215 B5 W227 |
211-215 | | R255 G255 B50 W255 |
216-220 | | R255 G255 B90 W255 |
221-225 | | R255 G255 B118 W255 |
226-230 | | R255 G255 B132 W255 |
231-235 | | R255 G255 B151 W255 |
236-240 | | R255 G255 B171 W255 |
241-245 | | R255 G255 B185 W255 |
246-250 | | R255 G255 B197 W255 |
251-255 | | R255 G255 B234 W255 |
10 | 0-3 | | No strobe |
4-107 | | strobe from slow to fast |
108-209 | | nonsynchronous strobe from slow to fast |
210-255 | | ramdom strobe |
11 | 0-2 | | No macro function |
3-25 | | close delaying dimmer |
26-50 | 9 | self-define on |
51-90 | | non |
91-130 | | Impulse change |
131-170 | | junp change |
171-210 | | fading change |
211-250 | | non |
251-255 | | non |
12 | 0-255 | | Macro speed |
13 | 0-255 | 10 | X fine(16Bit) |
14 | 0-255 | 11 | Y fine(16Bit) |
15 | 0-255 | | XY speed |
16 | 0-249 | | non |
250-255 | 12 | Reset after 4s |
FAQ:
Lighting Effect:
Xiang Jun Lighting Service
Factory | Guangzhou Xiangjun Lighting Equipment Co., Ltd. |
Brand | Xiangjun |
Price term | EXW price/FOB Shenzhen or guangzhou |
Min quantity | 1 set |
Payment terms | T/T, Western union |
Shipping Way | 1.By Express ( DHL, Fedex, Ups, EMS) 2.By Air 3.By Sea |
Sample time | 1-3 business days |
Production time | 5-20 days, but ultimately subject to order quantity |
Packing | 1.Using EPE packing the goods in case damage 2.Then put it into the Standard carton 3.Flightcase optional |
OEM | Available |
Warranty | 1 year |
After-sell Service | 1.If there is a problem with the product, please describe it and sent the necessary picture or video to us for analyzing. 2.Then we will guide you how to fix it and provide free accessories if required.. 3.For big problem, you can send the products to our factory, then we will send a new one to you! 4 We also could use remote control to handle with problem for you |
Used for | Stage/disco/KTV/night club//bar/big show/party/wedding,some other kinds entertainment places and so on. TV, station outdoor performance, high-rise buildings,Sports, Hotels, Parks, amusement parks,Tourist attractions |
Established in 2014, XiangJun Lighting Equipment Co., Ltd have been in stage ligthing field For 2 years. Our factory in Guangzhou covers an area of 1500 square meters. We make Beam moving head light, LED moving head light, PAR Light, Dance floor, follow spot, console and other accessaries. Our products are CE and RoHS certified. We have a strict regulation on quality control from material purchase, mass production and warehouse storage. We provide OEM for many big brands in China and overseas market.
As an export-oriented manufacturer, we work hard to achieve three points as below
1. Focus on market, we spend much time on up-to-date technology, latest functions and designs of stage lighting aroundworld. We Analyze customers' inquiries and requirements every month and Find out what products are popular and easy-to-use on different markets. Eventually, provide our customers the right and most cost effective product.
2. Focus on quality, Many customers pay high price for low quality and Many pay high price for high quality. What we do is provide high quality at reasonable price which make our customers pay less and gain more. We have strict regulation on quality control from material purchase, production and warehouse storage.
3. Focus on Service, For customers, beside price and quality, delivery time and after-sale service are very concerned. We have strong production capacity which can guarantee the delivery time.
