Description
. Special Light Sharp, like a small mountain. Very special 3D Picture
. High Quality EMC LEDs, make sure the high lm/W and long lifespan
. Standard package size: 600x600x55mm
. High lumens out put, it's suitable to install in office
. Special light body design, more beautiful and stable
. Light even, soft, high light transmittance of PC material
. Operating Temperature: -20°C~+45°C
. Storage temperature: 0°C~+60°C
. LED Life time: Mean time between failure (MTBF): 30000 hours
. PS: Low Ripple, High PF, High Efficiency
2D Light Intensity Distribution Curve
Illumination -Distance Curve
Features and Benefits
. Solid shell
. Easy to install
. Wide voltage input
. SMD 3030 LED
. LED Indoor Lighting
. High Color Quality with CRI Min. 80
. The unique visual effect
Key Application
. Hotels
. Conference/Meeting rooms
. Offices
. Hospitals
. Schools
. And other energy-saving and present high illumination index
Note & Warning
1. Please read the product specification, confirm the using environment is in Listed in.
2.When product plugged into power, please ensure the closure of the switch, prevent to get an electric shock.
3. When luminary light up, do not touch the luminary surface by hand.
4. This product is limited to indoor using.
5. Avoid installation in the heat source and thermal steam, corrosive gas and so on.
6. Product working environment temperature: - 10 ºC to 40 ºC
7. Open the packing, check the product, if there have any damage on products, please keep packaging and contact to LumiS company.
Published By:
LumiS technology © 2014 All Rights Reserved.
Company Information
LumiS Technology Co., Ltd is located in ShenZhen, China, which is a professional manufacturer of LED products that integrates research, production and sales. LumiS is a team focusing on LEDs, LED Modules and LED luminaries. To serve client better, we also provide other led lamp's accessories. Our experienced R&D team and sales team are young but professional. All of us have been serving customers over 4 years. We are aiming to provide full service on led luminaries solution from LEDs, driver to final production. Our engineers can offer the best solution when you design luminaries from the beginning. To be specific, when you design one luminary, LumiS can provide the LEDs with high quality and best price based on our professional knowledge. "Save Your Time, Improve Your Products".
Legal Disclaimer
Information in this document is provided in connection with LumiS technology products. With respect to any examples or hints given herein, LumiS hereby disclaims any and all warranties and liabilities of any kind, including without limitation, warranties of non-infringement of the product can be changed to improve the quality and/or performance without notice.
Product Parameter Table
|
Type |
Item |
Parameter |
|
Basic Parameter |
LED Type and Qty |
SMD3014*288 |
|
Input Voltage |
AC85-265V |
|
Main Material |
Metal |
|
Appearance |
Transparent |
|
Install Hole Size |
- |
|
IP Code |
IP44 |
|
Electric Parameter |
Color Temperature |
5000K |
|
Total Power |
36W |
|
Total flux(LM) |
>3500 |
|
Power efficiency |
>0.9 |
|
Power factor |
>0.9 |
|
CRI |
>80 |
|
Illuminance (6000k) |
- |
|
The Other Parameter |
Beam Angle(°) |
125 |
|
Efficacy(lm/w) |
>95 |
|
Luminaire efficiency |
>0.88 |
|
Insulation class |
I |
|
Installation |
- |
|
Product size |
600*600*55mm |
|
Cartoon Size/PCS |
1PCS |
|
Packaging style |
- |
|
Product/Box Weight |
1kg, 1.2kg |
|
Operating Environment |
-35°C-45°C |
|
Other |
Lifespan 30000H
|
