Features of LED miner's lamp
1 one high output 1 watt LED, six low output LEDs
2 two lighting levels: Maximum code and economic code
3 multi-function for mining and outdoor sports
4 rechargeable up to 1000 times
5 >20000 Hrs >1500lux at the maximum code
6 two years warranty
Brief introduction of LED miner's lamp
It adopts energy saving circuit, one 1W high-power LED main light source, six low-power LED accessorial light source. Safety lithium-ion battery integral design has many good characteristics, small volume, light weight, free maintenance, explosion- proof, waterproof, anti-knock and long lifetime. High capacity lithium-ion battery, long lifetime, low self-discharging rate, economical and environmental friendly. Run time for a fully charged could apply over 14hrs main lighting time, over 24hrs for accessorial lighting. It has elasticity webbing, and the irradiation angle canbe adjusted up and down, it is the environmental friendly which has the patent of high technology product.
Specifications of LED miner's lamp
Item ZH-T10W001
Charger AC input AC110-240 V
DC output DC4.2V/0.5A
Frequency 50/60Hz
Lithium-ion battery 2.8AH
Working time≥ 11h
LED power consumption 1W
Light illumination 1200-3200Lux (at 1m distance)
Color temperature(CT) 3000-6500K
Color rendering Index(CRI)Ra>80
Charging time 6h
Working temperature -20-40
Life-span 50000H
Body material PC
Net weight 0.385Kg.
IP degree IP65
Applications of LED miner's lamp
It is suitable for mine working, hiking, railroad and navigation.
Mode No |
Light Souree Type |
Main Lighting Current |
Accessorial Lihgting Current |
Main Lighting Voltage |
Accessorial Lihgting Voltage |
CCT |
3M
Illumination |
|
ZH-T10W001 |
COB |
150mA |
60mA |
3.0-3.4V |
3.0-3.4V |
5500-6000k
4000-5000k
3000-4000k |
1200-3200lux |
Shenzhen Cohon Lighting Co., Ltd. is a high-tech manufactory which is mainly engaged in technical research, production and service of LED semiconductor illumination. with an area of 5000 square meters, our company is equipped with numerous of advanced experimentation equipment and full automatic production pipeline of LED devices.
We have a very excellent design and R& D group who are professional in the field of LED application, external appearance, structure, illumination and drive electric source. Our company has employed doctors of Chinese Academy of Science as technology consultant. We have acquired many patents already, and now, more than ten products are under application for patents by our R& D hard working.
Our products include LED street light, LED headlights, LED miner's lamps, high power LED spotlights, LED emergency lights, LED floodlights, LED underwater lights and series of high-power LED commercial semiconductor lights. Besides, we also have developed capability of supply some special standard LED lighting products. And our products have passed the CE, UL and RoHS.
Our products have been exported to all over the world and they are welcomed by our customers, especially the series of 1W power LED miner's headlight has occupied more than 50% market in China. We will try our best to contribute all strength for the global green lighting and put more and better green semiconductor lighting products to the market.
