Product Description
6W Patent Scob Reflector Cup GU10 LED Spotlight (LS-S006)
Same Color bin for each order of SCOB products
Input voltage: AC/DC12V,100/240V,AC
Power: 6W SCOB reflector spotlight
Light Source: CREE Chip, Packaged by Leiso (SCOB)
Standard CCT: 2700K/3000K/4000K/5500K
Customized CCT: 1800K/2300K/2500K can be customized
CRI: 80Ra 90Ra available, 95Ra&98Ra can be customized.
Lumen: 400lm @ 2700K, 420Lm @3000K, 440Lm @ 4000K, 460Lm @5500K
Beam Angle: 36°
Base: GU10/MR16
Material: Dia-casting Aluminium
Certifications: TUV-GS, TUV-EMC, ERP, SAA CE RoHS Certificated
Operation Temperature: -20-50°
Warranty: 3 years Warranty
Lifespan: 45, 000hours
Features:
1: Halogen size and high lumens.( in current market, few factories can meet both the halogen size and high lumen ).
2: Rubycon electrolytic capacitor from Japan
3: For dimmalbe version, it is Philips NXP IC in dimmable driver, nice dimmable effect, it is the best one at the moment.
4: CE/ROHS/TUV-GS/TUV-EMC/ERP/SAA/CB certified
5: 3 Years warranty !
Notice
1. Make sure the power supplier is adapted to the right voltage before use;
2. Please insure that the switch is off before connect the power supplier;
3. Please dont touch the metal body and watch light source directly;
4. Indoor use only
Application:
Commerical lighting, Star Hotels, Shops, Shopping Malls and so on.
| Item No. | Pictures | Data sheet | Lumens (CCT) | Product Dimension | Voltage | Dimmable |
|
| LS-S006-GU10-BWW/BW |
| *6W SCOB GU10 spotlight
* reflector design
* CREE Chip
* Beam angle : 36°
* Power factor : >0.90
* Lifespan:≥35000Hrs | CRI >80, 400 lm (2700K)
CRI >80, 420 lm (3000K)
CRI >80, 440 lm (4000K)
CRI >80, 460 lm (5500K) | Φ50*H72mm | 100V~240V AC | NOT |
| LS-S006-GU10-A-BWW/BW |
| LS-S006-GU10-BWWD/BWD | CRI >90, 380 lm (2700K)
CRI >90, 400 lm (3000K)
CRI >90, 420 lm (4000K) | 220-240V AC | YES |
| LS-S006-GU10-A-BWWD/BWD |
| LS-S006-MR16-BWW/BW |
| *6W SCOB MR16 spotlight
* Reflector design
* CREE Chip
* Beam angle : 36°
* Lifespan:≥35000Hrs | CRI >80, 400 lm (2700K)
CRI >80, 420 lm (3000K)
CRI >80, 440 lm (4000K)
CRI >80, 460 lm (5500K) | Φ50*H66mm | 12V DC/AC | NOT |
| LS-S006-MR16-A-BWW/BW | CRI >90, 380 lm (2700K)
CRI >90, 400 lm (3000K)
CRI >90, 420 lm (4000K) |
| LS-S006-MR16-ED-BWWD/BWD |
| * 6W SCOB MR16 spotlight
* Reflector design
* CREE Chip
* Beam angle : 36°
* Lifespan:≥35000Hrs | CRI >80, 400 lm (2700K)
CRI >80, 420 lm (3000K)
CRI >80, 440 lm (4000K)
CRI >80, 460 lm (5500K) | Φ50*H66mm | 220-240V AC | YES |
| LS-S006-MR16-ED-A-BWWD/BWD | CRI >90, 380 lm (2700K)
CRI >90, 400 lm (3000K)
CRI >90, 420 lm (4000K) | Φ50*H66mm | 220-240V AC | YES |
Leiso lighting tech. Co., Ltd. (dongguan) is professional manufacturer for LED lighting integrate research & development, production, sales and service. The company offers complete product categories including LED lamp series, LED spotlight, LED bulb, LED t8 tube light, LED downlight, LED flexible tube light, LED module etc, which can be widely used in indoor lighting, outdoor landscape lighting, solar LED light, electronics, auto, communication, and so on.
Companies adhering to the philosophy of "customer priority, quality first " and the strategic policy of "quality, excellent service " to lead of energy saving LED lighting market. With years of experience in production and research and development. Excellent product quality recognition by our customers.
The factory total area of about 6, 000 square meters, high standards of clean production workshop, with automatic solid crystal, automatic wire bonders, automatic irrigation plastic, automatic color separation and packaging equipment. 300kk annual output more than the product of the making process of purification, anti-static work of international standard facilities closed. More than 200 employees, including 38 of engineering, QA and R & D staff.
"science and technology to create the future, quality creates brand. " LEISO based on domestic growth abroad. "quality first, customer first, innovation, service first"is the established policy of the company, to the colorful LED products, customers willing to form a close alliance, to add luster to the modern human.
