Home LED Light Products Reflector Cup LED PAR30-S 15 for E27/E26/B22 Base (PAR38-D)

Reflector Cup LED PAR30-S 15 for E27/E26/B22 Base (PAR38-D)

Reflector Cup LED PAR30-S 15 for E27/E26/B22 Base (PAR38-D)
Price: US $ 9-11/Piece
Trade Terms: FOB,CIF,EXW
Min Order: 5/Piece
Pay Type: L/C,T/T,Western Union
Reflector Cup LED PAR30-S 15 for E27/E26/B22 Base(PAR38-D)

1. Specification details

Power: 15W
Replacement 50W traditional incandescent bulb.
Input voltage : 100-240V AC
CCT: Customized from 1800-2500K, Standard CCT: 2700K, 3000K, 4000K, 5500K
Lumens: CRI >80, 1200 lm (2700K), CRI >80, 1350 lm (3000K)
                 CRI >80, 1450 lm (4000K), CRI >80, 1600 lm (5500K)
                 CRI >90,  950 lm  (2700K), CRI >90, 1050 lm (3000K)
                 CRI >90, 1150 lm (4000K), CRI >90, 1250 lm (5500K)
CRI: Ra80/Ra90 or customized 95Ra, 98Ra
Beam angel : 25 degree
Lamp base : E27/E26/B22
Products Size: Φ63.5*88mm
Dimmable: NOT
Warranty: 3 years free replacement
Lifespan: 35,000hrs

2. Advanges and characters
1) Adopt patented SCOB light source (stereoscopic chip on board).
2) Unique design makes it different from existing LED Bulbs of public mould.
3) Optically designed reflector keeps the same appearance and light distribution with traditional halogen lamp, which is easily accepted by users.
4) Long lifetime 35000Hrs(Calculated as 8 hours per day, average lifespan 10 years above).
5) No IR- and UV radiation.
6) Directly replace 75W halogen lamp, saving at least 80% energy.
7) TUV GS, CE, CB, SAA, EMC, ERP and RoHS obtained.
8) Customized color temperature from 1800K, 2200K, 2500K, and standard CCT: 2700K, 3000K, 4000K, 5500K
9) CRI 80 and 90 for choose
10) Materials: PC940. Excellent resistance Burning level V-0.
11) With PMMA cover on the lamp to pretect the dust-free.

3. Technical Parameters of P707 series PAR20 SCOB 7W
Item No.Data sheetPowerLumens (CCT)Product DimensionVoltageDimmablePacking Data
CTN
Qty
CTN
Dimension
Volume weightGross weight
LS-P707-BWW/BW* 7W SCOB PAR20
* Reflector design
* CREE Chip
* Beam angle : 25°
* E27/E26/B22 base
* Power factor : 0.95
*Lifespan≥35,000Hrs
7WCRI >80, 400 lm (2700K)
CRI >80, 420 lm (3000K)
CRI >80, 440 lm (4000K)
CRI >80, 460 lm (5500K)
Φ63.5*H88mm100~240V ACNOT6455x28x23cm8.0kg10.7kg
LS-P707-A-BWW/BW
LS-P707-BWWD/BWDCRI >90, 380 lm (2700K)
CRI >90, 400 lm (3000K)
CRI >90, 420 lm (4000K)
100~120V AC  220~240V ACYES64
LS-P707-A-BWWD/BWD
Prod Model: LS-P718-BWWD/BWD
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Lumens: 840~960lm
Cct: 2700k/3000k/4000k/5500k or Customized
CRI: Ra80 /Ra90 or Customized
LED Brand: Gree Chip
Light Source: Scob
Beam Angle: 25 Degree
Products Size: Diameter120*H130mm
Dimmable: Yes
Lamp Base: E26/E27/B22
Directly Raplace: 50W Tranditional Halogen Lamp
Emitting Color: Full Range
Power: 15W
Base Material: Aluminum
Usage: Decoration
Life: 50000h
Certification: CB
Power Source: AC
Electric Current Type: AC
LED Chips: CREE
Diffuser: Aluminum
IP Rating: IP20
Input Voltage: 220~240V AC or 100~120V AC
Leiso lighting tech. Co., Ltd. (dongguan) is professional manufacturer for LED lighting integrate research & development, production, sales and service. The company offers complete product categories including LED lamp series, LED spotlight, LED bulb, LED t8 tube light, LED downlight, LED flexible tube light, LED module etc, which can be widely used in indoor lighting, outdoor landscape lighting, solar LED light, electronics, auto, communication, and so on.

Companies adhering to the philosophy of "customer priority, quality first " and the strategic policy of "quality, excellent service " to lead of energy saving LED lighting market. With years of experience in production and research and development. Excellent product quality recognition by our customers.

The factory total area of about 6, 000 square meters, high standards of clean production workshop, with automatic solid crystal, automatic wire bonders, automatic irrigation plastic, automatic color separation and packaging equipment. 300kk annual output more than the product of the making process of purification, anti-static work of international standard facilities closed. More than 200 employees, including 38 of engineering, QA and R & D staff.

"science and technology to create the future, quality creates brand. " LEISO based on domestic growth abroad. "quality first, customer first, innovation, service first"is the established policy of the company, to the colorful LED products, customers willing to form a close alliance, to add luster to the modern human.
