Beam Moving head stage light 12pcs*10W(SH-Beam1210) Description:
A, Product Features
1) 50, 000 hours LED lifespan, low power consumption
2) LED Overheating protection function
3) High Efficiency 8 degree optical system
4) RGBW infinite color mixing possibility good for stage lighting
5) When full output power is 7M, the lumens will be 684
6) 0-100% liner adjustment, not blinking
7) 18 times/second high speed strobe effect
8) Random strobe and pulse strobe function
9) 15 international standard DMX channels
10) Built-in work auto programs with macro function
11) DMX512 signal, Master/Slave, sound active. Work auto
12) LCD display
13) Scanning high speed, smooth, quiet
14) High efficiency and low noise fan cooling system
B, Specification
1) Input voltage: AC90-260V 50/60Hz
2) QTY: 10W*12PCS 4 in 1 LEDs
3) Control signal: DMX 512, Master/Slave, work auto and sound active
4) DMX Channel: 15CH
5) consumption: 140W
6) 540 degree Pan scanning; 270 degree Tilt scanning
7) Scan position has memory and automatic reset function
8) IEC plug input
9) 45 degree maximum working environment
10) IP20 waterproof rate
11)3-Pin signal connector, power in/power out
12) Product Size: 152(D)*265(W)*304(H)mm
13) Packing Size: 260(D)*320(W)*335(H)mm
14) Net weight: 4.9KG
15) Gross Weight: 7KG
Channels of Beam Moving head stage light 12pcs*10W:
CH1 Dimmer
CH2 Red
CH3 Green
CH4 Blue
CH5 White
CH6 Color mixing
CH7 Pan
CH8 Tilt
CH9 Pan fine
CH10 Tilt fine
CH11 Speed of X/Y
CH12 Strobe
CH13 Color changing
CH14 Speed of color changing
CH15 Setup ID
NEW: RGBWA+UV IP65 LED PAR18pcs*15W With CE, ROHS, UL/led stage lights
Related Products: RGBWA+UV IP65 LED PAR 24pcs*18W With CE, ROHS, UL/led stage lights:
Why choose us?
1. Rich experience on manufacturing stage lighting!
2. At least 48hours QC Testing/Aging test!
3. On time delivery!
4.2years warranty!
5. Offer 7*24hours Service!
Shipment method
DHL, UPS, FEDEX, AIR CARGO, BY SEA Optional
|
Channel list |
Instruction |
|
CH1 |
Dimmer |
|
CH2 |
Red |
|
CH3 |
Green |
|
CH4 |
Blue |
|
CH5 |
White |
|
CH6 |
Color mixing |
|
CH7 |
Pan |
|
CH8 |
Tilt |
|
CH9 |
Pan fine |
|
CH10 |
Tilt fine |
|
CH11 |
Speed of X/Y |
|
CH12 |
Strobe |
|
CH13 |
Color changing |
|
CH14 |
Speed of color changing |
|
CH15 |
Setup ID |
