Items MPT-10.41
Pixel Pitch 10.416mm
LED Configuration SMD3535
Pixel Density 9216/sqm
Module Size(mm) 250mm(W)X250mm(H)
Module Resolution 24X24
Unit Size(mm) 500mm(W)X500mm(H)
Cabinet Material Die-casting Aluminum cabinet
Unit Pixel 48X48
Unit Weight 9Kg
Scan Mode 1/4
Brightness(CD/sqm) 5500CD/sqm
"Power Consumption
(max/avg)(W/sqm)" 690W/sqm (max), 230W/sqm (avg)
Transparency 23%
Driver IC MBI5042
Refresh Frequency 2800Hz
Gray Scale 16bit
Color Depth 65536
View Angle 120deg; (H). 90deg; (V)
IP(front/rear) IP65 (Front), IP54 (Rear)
Control system LINSN/NOVA
Working Temperature -30degree - +50degree
Operating Humidity 10 - 90%
Outstanding image quality and elegant,
Pixel level color and intensity calibration
Lightweight, yet strong
Fast to assemble, no tools.
Reliable, built to the highest standards
10.416mm pixel pitch, semi-transparent design.
