North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Tube Chip Color:
Full Color
Display Function:
Video Display
Pixel Pitch:
5mm
Pixel Configuration:
1R,1G,1B
Pixel Density:
10,000 dots / m²
Scanning Mode:
1/4 Scan
System Operating Platform:
WIN98
Display Type:
LED Video Display
Application:
Shopping Guide
IP Rating:
IP43
Certification:
ETL
Product Description
Wholsale P5mm Indoor LED Display for Advertising(480*480) . 1.Humanized structure designing guarantees the minimum assembly gap as 0.1mm between cabinets, Thickness of this cabinet is only 76.4mm 2.Equipped with patented fast locks,durable and graceful. Easy assembly and dismantling 3.Speedy heat venting designing ensures steady cooling of the cabinets even equipped no fans 4.A light base lessens the space,occupied by the display.
Products list and application area: 1. Indoor full color LED display: Equally or compactly make the red, green, blue color in one DOT, equally distribute at the panel, so make the whole display 2. Usually apply for physical sports, advertisement, bank, stock exchange, station, port, marketplace, telecommunication, department, school, monitor, restaurant, entertainment, 3. Full spec, such as P2.5mm,P3mm, P5mm, P6mm, P7.62mm, P8mm, etc
Parameters
Aluminum Die-casting Rental(480*480)
Pixel Pitch (mm)
4mm
5mm
6mm
Pixel density(pix/m2)
62500
40000
27777
LED Type
SMD2020
SMD3528
Viewing Angle
HZ:140°,V:140°
Brightness(nits)
1600
1500
1800
Drive Method
1/15
1/12
1/10
Driving IC
MBI5024
Color Depth
16bit
Refresh Rate(Hz)
600
1200
Module Size (mm)
240×240
Cabinet Size(mm)
480×480
Cabinet Material
Die-cast aluminum
Cabinet weight(kg)
9.5kg
Voltage
110/250V
Average.power(W / m2)
585
Max.power (W / m2)
1300
IP Grade
IP31
Operating temperature/humidity
temperature:-20ºC~ 50ºC humidity:10~90%RH
Storage temperature/ humidity
temperature:-40ºC~ 60ºC humidity:10~90%RH
Lifetime(h)
≥50000
Compliant Standard
CCC\CE
We are the leading OEM manufactures of LED Display Screens in China, which is professionally engaged in the production of Indoor, Outdoor and Semi-Outdoor LED Display screens in Single, Bi-color and Multi color for different markets such as Malls and Plazas, Traffic guiding signs, Entertainment and Stage, Shop sign boards and huge Media Bill Boards, Security Monitors etc. We are an ISO 9001: 2000 company, CE certified, RoHS certified, export licence holders.
Shenzhen Mary Photoelectricity Co., Ltd (MRLED) is a subsidiary of state-owned listed company-- Fujian FURI Electronics Co., Ltd. And was established in 2006 April, which the registered capital is 100 Million RMB. MRLED is a national level and high & new technology enterprise which specialize in designing, researching, manufacturing and selling all kinds of LED displays.
Experienced nine years of development, nowadays MRLED own its factory workshop area about 30, 000sqm, monthly capacity is 8000sqm, the number of employees more than 800. Company has the international first-class technology development talents and advanced production equipment, a comprehensive standardized management, product technology and quality is in the forefront between the similar products in domestic market. Also enjoy good reputation in the global market.
MR LED' products widely used in outdoor advertising, cultural and recreational activity, stadium, stage background rental, With its full color LED displays advantages, from the design, productions, installation to the maintenance, Use of comprehensive integration solutions, effectively reduce the overall cost for customers, so as to create more value for customers.
In past 8 years, MRLED service team almost traveled in all over the world, always uphold the core values of "Professional, Team, Integrity, Effectiveness, Communication", provide professional, caring, attentive after-sales service for global customers. Nowadays, MRLED's products selling to over 400 cities in autonomous regions and 34 provinces in China by virtue of high reliability and cost performance, earned thousands of customers, and also had built long term business relationship with the more than 90 countries' customers, like in USA, Germany, Spain, Portugal, Thailand, Korea, Poland, Italy etc. MRLED with its reliable quality, excellent service and good faith strives for realism style, won the user's high praise from all walks of life. No matter what's the major events & Competition venues in domestic and overseas, which like in the Guangzhou Asian games, the Shanghai world expo, each big TV station in domestic, railway stations, world beach volleyball tour, and Sydney autodrome, etc. All of them have a figure of MRLED.
