1. We have a strong team to design and develop new products according to customers' requirement. 2. We use high quality material, only do high-quality products, ensure that products comply with international certification standards. 3. Our strict producing process ensures 100% qualified rate of our products. 4. We are committed to provide pollution-free and free of charge products to the world.
1. High quality material, waterproof grade IP68. 2. High lumens and energy saving 60%-80%. 3. Isolated constant current driver with long lifespan. 4. Large beam angle 150° , lighting uniformity, no glare. 5. High quality light with a colour rendering index of 80.
Shipping 1. FedEx / DHL / UPS / TNT for samples, Door-to-Door; 2. By Air or by Sea for batch goods, for FCL; Airport/ Port receiving; 3. Customers specifying freight forwarders or negotiable shipping methods! 4. Delivery Time: 1-3 days for samples; 5-25 days for batch goods.
Payment Terms 1. Payment: T/T, Western Union, MoneyGram, PayPal; 30% deposits; 70% balance before delivery. 2. MOQ: 5pcs. 3. Warranty: 3 years. 4. Package Informations: 1 pcs per box /The volume of the box is 75cmx75cmx75cm
Φ90 - 3W
Type
XHX-UW3W01
LED brand
Epistar
Size
φ90*88
Lumens
240lm
Picking siz
125*125*145mm
CCT
2800-6500K
LED
high power 1W
CRI
≥ 75%
LED power
3W
Net weight/ Gross Weight
0.49kg/0.54kg
IP
IP68
Shiny surface
Φ60
Input
12V
Lift time
≥ 50 , 000Hours
2
Φ82 - 3W
Type
XHX-UW3W02
LED brand
Epistar
Size
φ82*100
Lumens
240lm
Picking siz
125*125*145mm
CCT
2800-6500K
LED
high power 1W
CRI
≥ 75%
LED power
3W
Net weight/ Gross Weight
0.49kg/0.54kg
IP
IP68
Shiny surface
Φ60
Input
12V
Lift time
≥ 50 , 000Hours
3
Φ120 - 6W
Type
XHX-UW6W
LED brand
Epistar
Size
φ120*75
Lumens
480lm
Picking siz
140*140*150mm
CCT
2800-6500K
LED
high power 1W
CRI
≥ 75%
LED power
6W
Net weight/ Gross Weight
0.75kg/0.82kg
IP
IP68
Shiny surface
Φ80
Input
12V
Lift time
≥ 50 , 000Hours
4
Φ160 - 9W
Type
XHX-UW9W
LED brand
Epistar
Size
φ160*75
Lumens
720lm
Picking siz
180*180*150mm
CCT
2800-6500K
LED
high power 1W
CRI
≥ 75%
LED power
9W
Net weight/ Gross Weight
1.2kg/1.4kg
IP
IP68
Shiny surface
Φ120
Input
12V
Lift time
≥ 50 , 000Hours
5
Φ175 - 12W
Type
XHX-UW12W
LED brand
Epistar
Size
φ175*95
Lumens
960lm
Picking siz
200*200*165mm
CCT
2800-6500K
LED
high power 1W
CRI
≥ 75%
LED power
12W
Net weight/ Gross Weight
1.6kg/1.8kg
IP
IP68
Shiny surface
Φ130
Input
12V
Lift time
≥ 50 , 000Hours
6
Φ185 - 18W
Type
XHX-UW18W
LED brand
Epistar
Size
φ185*95
Lumens
1080lm
Picking siz
200*200*165mm
CCT
2800-6500K
LED
high power 1W
CRI
≥ 75%
LED power
18W
Net weight/ Gross Weight
1.85kg/2kg
IP
IP68
Shiny surface
Φ120
Input
12V
Lift time
≥ 50 , 000Hours
7
Φ220 - 30W
Type
XHX-UW30W
LED brand
Epistar
Size
φ220*135
Lumens
2400lm
Picking siz
240*205*195mm
CCT
2800-6500K
LED
high power 1W
CRI
≥ 75%
LED power
30W
Net weight/ Gross Weight
2.35kg/2.4kg
IP
IP68
Shiny surface
Φ180
Input
12V
Lift time
≥ 50 , 000Hours
8
BESD-UW9B
Type
XHX-UW9B
LED brand
Epistar
Size
φ160*85
Lumens
720lm
Picking siz
180*180*100mm
CCT
2800-6500K
LED
high power 1W
CRI
≥ 75%
LED power
9W
Net weight/ Gross Weight
1.45kg/1.55kg
IP
IP68
Shiny surface
Φ180
Input
12V
Lift time
≥ 50 , 000Hours
9
BESD-UW12B
Type
XHX-UW12B
LED brand
Epistar
Size
φ180*85
Lumens
960lm
Picking siz
200*200*100mm
CCT
2800-6500K
LED
high power 1W
CRI
≥ 75%
LED power
12W
Net weight/ Gross Weight
1.75kg/1.85kg
IP
IP68
Shiny surface
Φ180
Input
12V
Lift time
≥ 50 , 000Hours
Xinhongxiang Optoelectronics (Shenzhen) Co., Ltd. As one of the most leading LED Products manufacturer in Shenzhen China, covering 10 000 square meters, register capital high up to 30 million CNY, is one high-tech enterprise focus on researching, producing, sale and service of LED products, . Nowadays Xinhongxiang owns fully automatic production lines, independent purifying workshop, researching center, most advanced production and inspection equipments, which guarantee the quality of the LED products. All the products have exported more than 100 countries, such as USA, Mexico, Canada, Brazil, Chile, Argentina, Panama, Colombia, Germany, France, Sweden, Italy, Spain, Russia, Poland, Turkey, Ukraine, South Africa, Egypt, Saudi Arabia, Singapore, Thailand, India etc
Developing History:
From 1996 to 2010, Xinhongxiang Optoelectronics (shenzhen) Co., Ltd, mainly involved in LED encapsulation and LED Display.
Since 2010, owe to enlarge the company scale and build up self-owned brand, Xinhongxiang focus on LED lighting, Shenzhen BESDLED Co., Ltd focus on LED display, business involved in indoor and outdoor LED Encapsulation, LED Display and LED Lighting Products.
LED Display:
Full Color Indoor and outdoor LED Display, single or dual basic color LED signs, LED Curtain, LED Dance Floor, Rental LED Display,
LED Lighting:
LED Bulb, LED Tube, LED Spotlight, LED DownLight, LED Panel Light, LED Street etc,
Comparing with many of LED Manufactures, xinhongxiang owns the following advantages to be your best choice for long term cooperation partner.
1, Fully automatic production lines
Xinhongxiang owns the entire LED manufacturing line, from original Semiconductor to LED chip, then assemble to LED display and LED lighting products.
2, Advanced production equipment
SMD/DIP die bolder, SMD/DIP wire Bolder, Auto Machine of Pouring Glue for SMD/DIP LED, Spectrum and Color Separation Machine, LED oven, Wave solder, Reflow soldering, Spectrum electronic and color tester, temperature and humidity programmable tester, luminance meter etc. Are equipped for our LED Product production.
3, Many Certification approved to clear up the trade barriers
CE, FCC, UL, RoHS, CCC, ISO9001: 2000 etc are obtained.
4, Strong R&D Team
Xinghongxiang absorb many talents, with more than 500 staffs, and including more than 100 engineers and technician, which paves the way for R&D for new products and excellent sales service
5): After-Service,
Principles: Response in time, solve problem ASAP and ensure the use.
Period: During warranty period, free of all maintenance charges;
