Usage Range:
Stage/ Theatre/KTV etc.
LED Source:
4PCS 10W RGBW 4in1 or Single White LEDs
Beam Effect:
2degree
Feature:
Each Mini Light Can Be Controlled One by One
Effect:
Rotating Beam Effect
N.W.:
12kgs
Dimensions:
1032X100X273mm
Material:
Aluminum Alloy
Control Mode:
Dmx Signal Control
IP Rating:
IP20
Certification:
RoHS
Light Source:
CREE 4-in-1 RGBW
Emitting Color:
RGBW or Single White
Control Channel:
6CH or 17CH for White LED , 6CH or 29CH for RGBW
Voltage:
AC90-260V, 50/60Hz
Product Description
Feature: 1. 4pcs 10W mini led moving head light team 2. Each mini lamp can be controlled one by one 3. 50000h lifetime, lower power consumption
Technical Parameter: Output Voltage: AC90-260V 50/60Hz 4pcs*10W White Lumileds LED/ 10W Cree 4-in-1 RGBW 50, 000Hours lifetime, low power consumption 4pcs moving head lights, could be controlled one by one Fast, accurate pan/tilt rotation Pan540° , Tilt: 270° Scan position memory function, reset function Beam Effect: 2 degree 18tims/s high speed strobe & pulse strobe function 0-100% nice linear dimming 12types Marco function 8pcs inner setting program 9CH or 19CH ( white led) DMX512, Sound-activation, mast-slave or auto-running Blue LCD screen Efficient, noiseless heat dissipation system Body size: 100(D)x1032(W)x273(H)mm
DMX Channel:
CH MODE
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
6CH
PAN
TILT
R DIMMING
G DIMMING
B DIMMING
W DIMMING
29CH
1
2
3
4
5
6
7
8
..
18
19
20
21
22
.
26
27
28
29
DIMMING
STROBE
R1 DIMMING
G1 DIMMING
B1 DIMMING
W1 DIMMING
R2 DIMMING
G2 DIMMING
..
W4 DIMMING
PAN 1
TILT 1
PAN 2
TILT 2
..
TILT 4
MOTOR SPEED
FUNCTION OPTION
DMX512 ID
Product show:
Guangzhou Baiyun Popular Stage Light Equipment Factory is a professional stage lighting manufactory which provides integrated services of research, production, marketing, after-sales inquiry, repair and maintenance. Our equipment are widely used in professional theater, entertainment centers, bars, parks, clubs, nightclubs and multifunctional units of conference halls. Compliant with CE and RoHS standards, our products main involve LED moving head lights, LED PAR lights, controllers, Moving head light, etc.
with strong beliefs in "Practical, Professional & Powerful" to the products, the company provides remarkably superb lighting Performance to all Professional Audience.
