Prod Model: |
SHTY-230 |
Markets: |
Southeast Asia,Africa,Mid East,Eastern Asia |
Solar Panel: |
Monocrystalline Solar Panel |
Battery: |
Lithium |
Solar Street Light: |
All in One Design |
Size: |
1170*330*140mm |
Cell Life: |
25 Years |
Solar Power: |
18V60W |
Charging Time: |
6hours |
Mounting Height: |
7-8m |
MOQ: |
10sets |
Delivery Time: |
5days 5000sets |
Power Supply: |
Solar |
Color Temperature: |
Pure White |
Lamp Body Material: |
Aluminum Alloy |
Power: |
30w |
Application: |
Garden |
IP Rating: |
IP65 |
Certification: |
RoHS |
Input Voltage: |
12v |
With Light Source: |
With Light Source |
LED Chips Brand: |
Bridgelux |
Product Description
Description:
1.All in one solar garden&street lights, new solar panel products...from 8w to 40w
2.Integration design, solar panel, led, battery, controller all in one
3.What you need to do when you receive them is to put them on the pole or wall, easy to install, ship and maintain, energy saving.
1.Using high capacity and long life of lithium from phosphate battery.
2.Using solar panel, led lamp for saving energy.
3.Rain-proof structure, waterproof rating is IP65.
4.With different power control. Reducing luminance auotmatically.
Specifications:
Integrated Solar LED garden/street light(8w-40w) |
Model | SHTY-208 Without sensor | SHTY-212 | SHTY-215 | SHTY-220 | SHTY-225 | SHTY-230 | SHTY-240 |
solar panel | Max power | 18V/15W | 18V/18W | 18V/30W | 18V/40W | 18V/50W | 18V/60W | 18V/60W |
Life time | 25 years |
Battery | Type | Lithium iron phosphate battery |
Capacity | 12.8V/6AH | 12.8V/6AH | 12.8V/12AH | 12.8V/18AH | 12.8V/21AH | 12.8V/24AH | 12.8V/27AH |
Life time | 5 years |
LED Lamp | Max power | 12V 8W | 12V 12W | 12V 15W | 12V 20W | 12V 25W | 12V 30W | 12V/40W |
led chip | Epistar | Bridgelux |
lumen (LM) | 800-880lm | 1200-1320lm | 1500-1650lm | 2000-2200lm | 2500-2750lm | 3000-3300lm | 4000-4400lm |
led chip | 63pcs | 117pcs | 216pcs | 288pcs | 24pcs | 40pcs | 40pcs |
Life time | 50,000hours |
Viewing Angle | 120° |
charging | by sun | 6 hours | 6 hours | 6 hours | 7 hours | 7 hours | 7 hours | 7hours |
lighting | full power | >12 hours |
half power | >24 hours |
work temp | range(°C) | -30°C~+70°C |
colour temp | range(k) | 6,000k |
Height | range (m) | 3-4m | 3-4m | 4-5m | 5-6m | 6-7m | 7-8m | 7-8m |
Space | range (m) | 8-10m | 8-10m | 10-15m | 18-20m | 18-20m | 18-20m | 18-20m |
Material | aluminium alloy |
Certificate | CE / ROHS / IP65 |
warranty | 2years |
Packing & Weight | productsize(mm) | 540*320*55mm | 710*350*55 | 920*330*140 | 1170*330*140 | 1170*330*140 | 1170*330*140 |
product weight | 5.8kg | 5.8kg | 8.0 kg | 12.5kg | 16kg | 16.5kg | 17kg |
packing box | neutral |
Corton size(mm) | 560*570*410 | 560*570*410 | 730*440*450 | 950*410*210 | 1210*410*210 | 1210*410*210 | 1210*410*210 |
Q'ty/ctn | 4set/ctn | 4set/ctn | 3set/ctn | 1set/ctn | 1set/ctn | 1set/ctn | 1set/ctn |
GW.for corton | 27kg | 27kg | 28kg | 15 kg | 18.5kg | 19kg | 20.5kg |
Packs Containers | 20GP | 900sets | 900sets | 639sets | 375sets | 300sets | 300sets | 300sets |
40GP | 1920sets | 1920sets | 1290sets | 792sets | 660sets | 660sets | 660sets |
Advantage:
Integrated design
Easy to install
Sell sufficient
No Electrical Cost
No wires or cables needed
Long life lithium battery
Customized design
Application
What is "all in one/integrated solar street light"?
All In One Solar Street Light:
The design inspiration absorption from the universe, Integrated with the optimal combination of green energy (solar energy, LED, lithium battery).
It uses intelligent microcomputer control system, combining with the minimalist design, perfect realization of low power and high brightness and long life performance requirements, at the same time the waterproof radiation performance is very good.
Note:
1. Please do not open the products by yourself.
2. Handle with care.
3. When first time use the solar garden light, you must make sure fully charge the battery.
