Prod Model: |
PL-P-S6W |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
LED Type: |
2835 SMD LED |
LED Qty: |
30PCS |
Power: |
6W |
Lumen: |
570lm |
Color: |
White,Warm White |
CRI: |
>80 |
Size: |
120X20mm |
Light Source: |
LED |
Appearance: |
Square |
Type: |
Embedded |
Certification: |
RoHS |
Voltage: |
100-240V |
Dimmable: |
With Dimmable |
Emitting Color: |
2700-7000k |
Housing Material: |
Aluminum Alloy |
Beam Angle: |
120 Degree |
Product Description
6W Round recessed led panel light
Main Features:
1. High efficiency(95%) constant current driver with built-in overheat protection that remain stable at a wide range of input voltage.
2. High brightness up to adopting side light technology. Using good reflectivity light leading board, it is thinner and brighter, the light is more equally
3. Low voltage and constant current driver, no glare, the light is soft
4. Using high lumen SMD light source, high intensity aluminum shell, heat faster
5. High brightness SMD 2835 led lighting sourcem, about 120-130lm/w.
6. Launch in 0.01 sec, no flashing, no noise or no radiation. Energy saving belongs to grand environmental lights
7. Long service life, high luminous efficiency
8. Dimmable is also available
9. Combination with technology and art, showing high brightness without seeing the lamp itself
10. CE $ RoHS certificate
Typical application
1. Office lighting
2. Home lighting
3. Commercial lighting, such as supermarket, shopping mall etc.
4. Hotel and restaurant lighting
5. Public lighting
Installation instruction
1. This product is limited to use indoor
2. Hold size of ceiling should be the same as the lamp's cutout size
3. Connect the DC connectors with the lamp and the driver
4. Insert the pinch to the ceiling, make sure it is fastened
Caution:
1. Confirm the goods have no damage during the transportation before using
2. Packing materials should be stayed away from the children, prevent children from playing the plastic bag and small accessories lead to suffocate or swallowed.
3. Put away from the children, do not let the children touch the lamp when it is working
4. Do not cover any things on the products. Put away from the fire or any other high temperature object
5. Lay people can not tear down or maintain the product. We have the authority to refuse giving any warranty to the products which are repaired without our instruction
6. Please shut off the power before clean the lamps. Only use the dry dish cloth to clean, do not use any chemical or corrosive material to the lamp
Item NO. |
Description |
PL-P-S6W |
Input voltage:100-240V
LED:30pcs 2835smd led
LED power:6W
Lumen:570lm
Color:white,warm white
Size:120X120mm |
PL-P-S12W |
Input voltage:100-240V
LED:60pcs 2835smd led
LED power:12W
Lumen:1140lm
Color:white,warm white
Size:170X170mm |
PL-P-S18W |
Input voltage:100-240V
LED:90pcs 2835smd led
LED power:18W
Lumen:1700lm
Color:white,warm white
Size:225X225mm |
PL-P-S20W |
Input voltage:100-240V
LED:100pcs 2835smd led
LED power:20W
Lumen:1900lm
Color:white,warm white
Size:300X300mm |
Pros Light is an established high-tech factory specialized in the research, development, engineering, and marketing of LED based lighting solutions. We have professional engineers always staying at the forefront of LED technology. We are especially well-placed in the field of Power LED thermal management and related lighting solutions.
Our product range:
1. LED Street Light
2. LED Bulb & Spotlight
3. LED Downlight
4. LED Panel
5. LED WallWasher & Floodlights
6. LED Explosion proof Light
7. LED High bay light
8. LED Tube T8
9. OEM & ODM Projects
