LED Encapsulation:
SMD3535
Module Size:
250X250mm
Module Resolution:
28X28dots
Cabinet Size:
500X500mm
Tube Chip Color:
Full Color
IP Rating:
IP65
Pixel Configuration:
1R, 1G, 1B
Display Function:
Video Display
Average Power Consumption:
300W / m²
Display Type:
LED Video Display
Certification:
RoHS
Pixel Pitch:
8.928mm
Pixel Density:
12544dots/Sq.M
Scanning Mode:
1/7
Application:
Advertising,Stage Performance,Rental
Product Description
P8.928 Full Color LED Display/LED Curtain for Show/event stage background with good waterproof for indoor and outdoor use, light weight and cheaper cost
Product Features:
1. SMD led encapsulation confirm wide view distance and good uniformity
2. Good waterproof IP65,long life span>100,000Hours
3. High pixel density, Long view distance, High definition, Good display vision
4. With 500x500mm and 500x1000mm panel size,easy for different sizes and combined randomly,better for rental use with different screen sizes
5.Slim Aluminum Cabinet,light weight, easy to move and portable, and quick to assemble and dismantle by hands
6. low power consumption, low noise created, energy-saving 30%
More pictures for reference:
P8.928 full Color LED Screen/Curtain Specification
Pixel pitch
8.928mm
Pixel Configuration
1R1G1B
LED component
SMD3535
Size of module
250mm*250mm
Resolution of module
28x28dots
Size of cabinet
500mm x 500mm/500mm x1000mm
Resolution of cabinet
56 x 56dots/56x112dots
Material of Cabinet
Aluminum
Weight of Cabinet
7.5kgs / 13KGS
Brightness
>4500cd/sq.m
Density
12546dots/sq.m
Best viewing angle
140° /140°
Pixel Configuration
1R1G1B
Best viewing distance
8-100M
Maximum power consumption
700W/sq.m
Average power consumption
350W/sq.m
Driving method
1/7 scan
Control method
Synchronization
Gray scale
65536
Colors
256*256*256
Color temperature
3200-9300k
Uniformity
97%
Working voltage
AC220V/110V±10%
Working temperature
-20ºC~+50ºC±10%
Working humidity
10%~ 90%
MTBF
10,000 hours
Frame frequence
50/60Hz
Refresh frequence
>1920Hz
IP grade
IP65
Life Span
100,000 hours
Data transafer method
RJ45
Pratical standard
CCC TUV-CE ETL etc.
Effectivce Communication Distance(without relay)
Unshielded twisted pair net line transmission distance:100M, max transmission distance:130M; Multi-mode optic fiber: 500M; Single-mode optic fiber: 10KM
Accepting signal with video processor
PAL/NTSC/SECAM,S-Video;VGA;RGB;HDMI,DVI,Composite Video;SDI,DP etc.
Systems operating platform
WINDOWS(WINXP,WIN7/8/10), and interfaces for secondary development
PRT OPTOELECTRONIC Co., Ltd is located in Bao'an District of Shenzhen city, specializing in R&D, manufacturing LED display screen and some related LED lighting, owned several new-automatic production lines and advanced test equipments to control quality. And got the international standard certificates of ISO9001-2000 and 14001, CE, CCC, FCC, RoHS.
Our main products include full color LED display, Outdoor LED display, Indoor LED display, Rental LED screen, Stage LED curtain screen, Sport stadium LED screen, Mobile LED screen etc. Also supply LED professional stage light, LED decoration lights, LED panel light, based on some customer' s request.
Our subcompany named PRT International Trade Co., Ltd, who in charge of exporting business, members with rich exporting experience over ten years, guarantee the products to be shipped out smoothly, so we can provide our clients high quality products with competitive prices and excellent service, and obtained a good reputation from our customers.
Our company's operating philosophy, "Quality is everything, Service is the key to success ", because our purpose is to let business done easily and trustingly, to save customer's searching time and purchase cost, solve problem on customer's position, to let everything to be "PERFECT"(abbreviated to"PRT" )!
PRT is a developing company, need hard work of our staffs, also need your large positive support, let us do business and develop together, "sincere cooperation, mutual benefit and common development" is our principle.
