Model No.:
P3.91 Indoor Full-Color LED Display
Module Size:
250mm*250mm
Package Mode:
SMD2121
Pixel Resolution:
64dots(W)*64dots(H)
Max Power Consumption:
32W
Module Weight:
0.573kg
Port Type:
Hub75-a
Brightness:
≥1200CD/M²
Cabinet Size:
500mm*500mm
Best Viewing Distance:
4m-20m
Tube Chip Color:
Full Color
Display Function:
Video Display
Pixel Configuration:
1R,1G,1B
Scanning Mode:
1/16 Scan
System Operating Platform:
WIN XP
Display Type:
LED Video Display
Application:
Shopping Guide
IP Rating:
IP60
Certification:
FCC/EMC
Pixel Pitch:
3.91mm
Pixel Density:
65536DOT/M²
Product Description
Our products: We specialize in producing and developing all kinds of led displays. As a reliable LED Display manufacturer and exporter in China, we supply Indoor led displays, Outdoor led displays, semi-outdoor led displays.Please kindly tell me which kind of the item you prefer to and provide me more information. It will help us to give you a good price.
Our features and advantages: 1.High quality: Use high quality LED with high luminous efficiency and low brightness decay to make the display stable.
2.Good effect: To show vivid and clear pictures with high resolution, but low cost; Has good display effect in both pictures and letters because of using real pixel technology.The products support multiple display modes.
3.Easy maintenance: Can fix the single point to save the maintenance cost.
4.Good uniformity: Brightness difference within 10% between any two LEDs, to ensure the brightness and color uniformity of the display; Good uniformity in color solve the problem of mosaic well
5.Price No. 1 cost effective. The price is very good, please contact us for an offer. You can compare and know!
6.Application It's wide Application, such as stage rental events, exhibition, wedding, advertising, meeting room and so on.
FAQ: 1. Are you manufacturer? If yes, in which city? Yes, we are the professional manufacture of LED display, and we work on it more than 10 years. Our company in Shenzhen, Dongguang, China.
2. Can I visit your factory ? We warmly welcome customers visit us. Before you come here, please kindly tell me your schedule, we can arrange for you. The nearest airport is Bao'an Shenzheninternational airport. 3. How about your quality warranty? 2 years quality warranty and lifetime technology support and maintenance from the second year. If you improperly operate or something wrong with our products, we are responsible for the maintaining and repairs instruction or guide free of charge.
Remarks 1.Payment term: 30% T/T in advance and balance before delivery.
2.Delivery time: Within 15 working days after 30% advance payment.
3.Free training: You can send your engineers who have knowledge of electronics and information to our factory and we provide free technical training, which contains training operation and maintenance of the LED display at our factory. We also offer the instruction manual, software, test report, drawing steel structure and so on.
4.Installation: We offer you the engineer to install the LED display, you have to offer him the two-way air tickets and accommodation as well as visa. The engineer's salary is $80/day;or we offer you the training on the LED display installation and repairing for free after you live in our company, or we can guide you to install the screen by remote control.
5. After service sales: If you have any questions about our product, you can inform us by mail or call, and we will reply you in 24 hours when we get you E-mail or call, and offer you a good solution for your problem.
Unit Module
Item
parameter
Model
ALS - P3.91 - 16S
Module size
250mm*250mm
Pixel Pitch
3.91mm
Pixel Density
65536dots/m2
Pixel Configuration
1R1G1B
Package mode
SMD2121
Module Resolution
64dots(W)*64dots(H)
Max power consumption
32w
Module Thickness
14.66mm(without magnet) 26.55mm (with magnet )
Module Weight
0.573kg
Driving Method
Constant Current Driving
Scan Method
1/16scan
Interface Way
HUB75E
Brightness
≥1200cd/m2
Unit Module
dimension
500mmx500mm
Quantity of Module
4
Thermal discharge
fan 1pcs
Power supply Mode
5V/60A* 1pcs
Pixel per cabinet
128mm*128mm
Thickness
65mm
Optimal Viewing Distance
4M-10M
Optimal Viewing angle
160°(W)120°(H)
Enviroment Temperature
Storage :-35ºC-+85ºC work :-20ºC-+50ºC
Power
Relative Humidity
20%-90%
Operating Voltage
AC220V±10%
Average power consumption
168WH
Max power Consumption
≤560W/m2
Current
≤20mA (Single LED )
Control system
CPU
Pentium4 or above P4 or above
Operate system
WIN98/2000/NT/XP
Control Mode
Synchronization with PC
Main technical parameter
Driving Device
IC Constant current driving
Refresh Rate
≥900HZ
Gray/Color
4096 gray grade, can display 16.7M clolor
MTBF
≥9000hours
Power Switch
Automatic Switch
Display Mode
800*600/1024*768
HD indoor led display screen P3.91mm
Our company supplies different kinds of products. High quality and favorable price. We're pleased to get your Inquiry and we will come back to as soon as possible. We stick to the principle of "quality first, service first, continuous improvement and innovation to meet the customers" for the management and "zero defect, zero complaints" as the quality objective.
