Remarks: cabinet size can changed, upon project need.
Power
Working voltage
AC220V/110V± 10%
Average power consumption
250-480W
Max. Power consumption
≤ 560W/sqm
Current
≤ 20mA(single LED)
Control system
CPU
Pentium4 or above
Operating system
WIN98/2000/NT/XP
Control method
Synchronization
Main technical parameter
Driving device
Static scanning
Drive type
Constant Current driver IC
Refresh frequency
≥ 400Hz
Grey scale/colors
256 levels of each color(R/G/B)/16.7M color
Brightness of white balance
More than 8000cd/sqm
Brightness adjustment
256 levels of each color(R/G/B)by software
Operating ambient humidity
10%--95%
Video signal
PAL/NTSC
Control system
DVI display card+full color controller card
MTBF
≥ 10, 000hours
Life span
≥ 100, 000hours
Flatness
Tolerance of interpixel ≤ 0.3mm
Tolerance of modules clearance≤ 0.6mm
Power switch
Automatic switch
Display mode
1024*768
Communication distance
Unshielded twisted pair net line transmission distance 100m, max transmission distance 200m. Multi-mode Optic fiber transmission distance 500m; Single-mode optic fiber transmission distance 10KM
Software
LED media player
Shenzhen Foxgolden Technology Limited, is one of the most impressing Hi-tech enterprises in China. Since 2004, we have been dedicating to the aim that making high quality products, and have been well integrated with R&D, production, project, capital and marketing.
As a professional and market-oriented LED display manufacturer, FOXGOLDEN not only keeps improving on normal LED display screen, enhances the product's cost-effective and overall market competitiveness, but also makes breakthrough progresses on special usages. Our products, with high quality and competitive prices, spread worldwide and earn excellent public reputation from both domestic and overseas market.
Foxgolden provides a full series of LED display products involving various single and dual color, text & image display; Indoor single & dual color, full color screen; Outdoor single & dual color, full color display; DOT matrix module display; Traffic applied product; And series of indoor & outdoor module.
Our company has provided our indoor & outdoor displays for various kinds of locations and events throughout the world. With high quality and perfect after-sale services, our professional products and solutions are highly complimented by the users, and we also earned high credibility from them.
With cultivation for high-quality production management team and project team, high quality products and local maintenance service; We achieved zero complaint in product quality for 3 constant years. That's why Foxgolden has received comprehensive attentions from LED industrial experts these years.
