Life Span:100,000h:
Full White Brightness:More Than 7000CD/Sqm
Control Mode:Synchronous Control:
Module Size:256mm*128mm
Best View Distance:8~150m:
View Angle:V110 Degree,H90 Degree
Tube Chip Color:
Full Color
IP Rating:
IP65
Pixel Pitch:
16mm
Pixel Configuration:
1R, 1G, 1B
Display Function:
Video Display
Display Type:
LED Video Display
Application:
Stage Performance
Certification:
FCC
Average Power Consumption:
850W/Sqm
Pixel Density:
3906
Scanning Mode:
4s
Product Description
Brilliantopto co.,limited (Jingcai(fujian) photoelectronic co.,ltd ) professional development manufacturing LED display system products and lighting products, was founded in 2005, with the registered capital 20.18 million, own workshop area 20000 m2, branch office and agents cover all over China, with about 400 employees.
Why choosed us :
1.Price Advantage: No.1 cost effective 2.Quality advantage: serious QC control system , best material 3.Service advantage: after service dept& Tech Dept. Perfect after sales system
Products list 1. P3\P4\P5\P6...indoor full color led display; 2.P10/P12/P12.5/P16/P20/P25...outdoor full color led screen; 3.Indoor/outdoor/semi-outdoor single/dual color led panel etc.
Pixel pitch
16mm
Module size
256*128mm,256*256mm
Module density
3906dots/sqm
Module resolution
25.6*12.8,25.6*25.6
Pixel configuration
1R1G1B
Red wavelength
OPTO taiwan 625±2nm
Green wavelength
Silan taiwan 525±2nm
Blue wavelength
Silan taiwan 470±2nm
Best viewing distance
From 10 to 150
Horizontal viewing angle
110°
Vertical viewing angle
90°
Maximum power consumption
Below 800W
Brightness
7500cd/sqm
Gray scale
More than 4096
Control method
Synchronization
Driving method
4Sconstant current
Frame frequency
60Hz
Refresh frequency
More than 300 Hz
Working voltage
AC220V±5%
IP grade
IP65
Working temperature
-20°C±50°C
MTBF
More than 5,000 hours
Life span
More than 100,000hours
Cabinet style
Waterproof cabinet
Cabinet size
W640*H640*D120mm
Cabinet weight
Less than 28kgs
Jingcai (Fujian) Photoelectric Co., Ltd. Was founded in 2005, with a registered capital of 20.18 million Yuan, a workshop covering an area of 20000 square meters and independent living and production places. Our company is professional in the development and manufacture of LED display systems. Our company technology strength is among the front row in this area, with a vigorous team.
In March, 2011, our company independently researched and developed a full-color formal P16 LED display, which can completely replace the current market single color LED displays, being the perfect choice in the next line of LED display market. In June, 2011, after designing P10 optical modules, we ceremoniously rolled out P10 light module series, which can effectively enhance the efficacy by above 10% and can effectively avoid a screen phenomenon. In August, 2011, our company took the lead in Quanzhou LED industry technology innovation strategy alliance. As the President unit, our company set up "Quanzhou LED Technology Research Center", featuring the national quality supervision center. Our company has many experts and professors from Xiamen University Semiconductor Research Center, Fuzhou University and Beijing University Institute of Photoelectricity for our research center technology consultation to comprehensively promote Quanzhou LED industry. In November, 2011, relying on our strong technical research and development team, we made a new generation of international leading 3D display screens.
Through six years of unremitting efforts, our company has successively obtained such honorary titles as The State Ministry Of Small-Sized And Medium-Sized Enterprise Technology Innovation Fund Project Unit, Small-Sized And Medium-Sized Enterprise In Fujian Province Technology Innovation Fund Project Unit, ISO9001 International Quality Management System Authentication Enterprise, CCC China National Mandatory Product Certification Enterprise, CE Compulsory Product Certification Enterprise, FCC Anti-Radiation Product Authentication Enterprise, RoHS Lead-Free Environmental Protection Product Authentication Enterprise, IP65 Waterproof and Dustproof Product Authentication Enterprise, Chinese Optical Optoelectronic Industry Member Unit, National Taxpayer Service Work Outstanding Member Unit, Unit With 15 Independent Research And Development Patents Of The State Intellectual Property Office, Fujian Quality And Right Protection Service (Member) Unit, Fujian Integrity And Labor Advocate Unit, Quanzhou Industry And Commerce Credit Good Enterprise, Quanzhou Creditable Unit, Quanzhou LED Technology Research Center and Quanzhou LED Industry Technology Innovation Strategy Alliance Chairman Unit.
Our company always implements our development target and insists on the tenet of "customers are the growing power source". Our company has a perfect after-sales service system, truly realizing that customers are the centers of the market marketing model.
Through our efforts, our products have been sold well in Europe, North America, Australia, the Middle East and Southeast Asia. Our company has set up stable sales agents in the corresponding areas. Our company sincerely hope to cooperate with LED display system talents and dealers for common development and for the development of LED display systems.
