North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Tube Chip Color:
Full Color
IP Rating:
IP43
Pixel Pitch:
12mm
Pixel Configuration:
2R, 1G, 1B
Display Function:
Video Display
Average Power Consumption:
350W / m²
Scanning Mode:
Static Scan
Display Type:
LED Video Display
Application:
Stage Performance
Certification:
ETL
Pixel Density:
22545 DOT/M2
Product Description
P10mm Flexible LED Display with Soft and Transparent, Flexible LED Display for Stage Rental
Patented Piranha LED and SMD3535 are used for this model, which guarantee a wide viewing angle(>140°H;>140°W) and a nice flatness appearance. Brightness>5500CD/SQM. Graceful and concise appearence, <0.1mm discrepancy aluminmum die-casting moulding criterion, no deformation; light weight, slim body; with Protection grade IP65 front and IP54 rear. Suitable for all outdoor working environment. Fast locks at the four sides of the cabinet, easy assembly; and be piled up and be hoisted. Backside maintenance. Exterior exposed module screws, easy dismantling. Waterproof connectors, safe and steady.
Parameters
640 Die-casting series
Pixel Pitch (mm)
6.66mm
8mm
10mm
16mm
Pixel density(pix/m2)
22545
15625
10000
10000
LED Type
SMD3535
SMD3535/DIP5454
SMD3535/DIP5454/DIP346
DIP5454
Viewing Angle
X\Y140°
X\Y140°/X\Y120°
X\Y140°/X\Y120°/X120°\Y50°
X\Y120°
Brightness(nits)
4500
4500/5500
5500
5500
Drive Method
1/6
1/5
1/2\1/4
1/2
Driving IC
MBI5024
Color Depth
16bit
Refresh Rate(Hz)
1000
1200
1800\1200
1800
Module Size (mm)
320×160
Cabinet Size(mm)
640×640
Cabinet Material
aluminum
Cabinet weight(kg)
13.5
Voltage
200-240V
Average.power(W/m2)
330
625
Max.power (W/m2)
735
750
1350
IP Grade
IP65/IP54
Operating temperature/humidity
temperature:-20°C~ 50°C humidity:10~90%RH
Storage temperature/ humidity
temperature:-40°C~ 60°C humidity:10~90%RH
Lifetime(h)
≥50000
Compliant Standard
CCC(S&E)RoHS
We are the leading OEM manufactures of LED Display Screens in China, which is professionally engaged in the production of Indoor, Outdoor and Semi-Outdoor LED Display screens in Single, Bi-color and Multi color for different markets such as Malls and Plazas, Traffic guiding signs, Entertainment and Stage, Shop sign boards and huge Media Bill Boards, Security Monitors etc. We are an ISO 9001: 2000 company, CE certified, RoHS certified, export licence holders.
Shenzhen Mary Photoelectricity Co., Ltd (MRLED) is a subsidiary of state-owned listed company-- Fujian FURI Electronics Co., Ltd. And was established in 2006 April, which the registered capital is 100 Million RMB. MRLED is a national level and high & new technology enterprise which specialize in designing, researching, manufacturing and selling all kinds of LED displays.
Experienced nine years of development, nowadays MRLED own its factory workshop area about 30, 000sqm, monthly capacity is 8000sqm, the number of employees more than 800. Company has the international first-class technology development talents and advanced production equipment, a comprehensive standardized management, product technology and quality is in the forefront between the similar products in domestic market. Also enjoy good reputation in the global market.
MR LED' products widely used in outdoor advertising, cultural and recreational activity, stadium, stage background rental, With its full color LED displays advantages, from the design, productions, installation to the maintenance, Use of comprehensive integration solutions, effectively reduce the overall cost for customers, so as to create more value for customers.
In past 8 years, MRLED service team almost traveled in all over the world, always uphold the core values of "Professional, Team, Integrity, Effectiveness, Communication", provide professional, caring, attentive after-sales service for global customers. Nowadays, MRLED's products selling to over 400 cities in autonomous regions and 34 provinces in China by virtue of high reliability and cost performance, earned thousands of customers, and also had built long term business relationship with the more than 90 countries' customers, like in USA, Germany, Spain, Portugal, Thailand, Korea, Poland, Italy etc. MRLED with its reliable quality, excellent service and good faith strives for realism style, won the user's high praise from all walks of life. No matter what's the major events & Competition venues in domestic and overseas, which like in the Guangzhou Asian games, the Shanghai world expo, each big TV station in domestic, railway stations, world beach volleyball tour, and Sydney autodrome, etc. All of them have a figure of MRLED.
