| Prod Model: |
NO |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Product Name: |
P10 SMD Outdoor Advertising LED Billboard Display |
| Brightness: |
6500nits |
| Contrast: |
≥2000:1 |
| Maintenance: |
Front/Back |
| LED Configuration: |
DIP346 |
| Warranty: |
2 Years |
| Life-Span: |
50,000 Hours |
| Best Viewing Distance: |
12.5-33m |
| Gray Scale: |
≥12bit |
| Refresh Frequency: |
≥800Hz |
| Tube Chip Color: |
Full Color |
| IP Rating: |
IP65 |
| Pixel Configuration: |
1R, 1G, 1B |
| Pixel Pitch: |
10mm |
| Display Function: |
Video Display |
| Scanning Mode: |
1/4 Scan |
| Certification: |
ETL |
| Pixel Density: |
10000 dot / m² |
| Average Power Consumption: |
180W / m² |
Product Description
General discriptions
Uniview NO/NI series adopts standard cabinet design, strong steady and endurable structure. We also calibrated and optimized the balance between led brightness, color and contrast which made excellent color uniformity.
Features
1. For outdoor application, pixel pitch range from 10mm to 25mm
2. SMD 5050 and DIP are available
3. MBI 5050, 5042 and 5024 are availiable
4. Cabinet size could be customized
5. Front or back maintenance
6. Hight brightness, IP65
Typical Applications
7. Outdoor billboard
8. Stadium advertising
|
NO Series |
NO-10 |
NO-12 |
NO-16 |
NO-20 |
|
Pixel Pitch |
10mm |
12mm |
16mm |
20mm |
|
LED Configuration |
DIP346 1R1G1B |
DIP346 1R1G1B |
DIP346 1R1G1B |
DIP346 1R1G1B |
|
Pixel Density |
10000/m² |
6944/ m² |
3906/ m² |
2500/ m² |
|
Unit Size(mm) |
960(W)*960(H)*140(D) |
960(W)*960(H)*140(D) |
1024(W)*768(H)*140(D) |
1024(W)*768(H)*140(D) |
|
Unit Resolution |
96*96 |
80*80 |
64*48 |
64*40 |
|
Module Size(mm) |
160(W)*160(H) |
192(W)*192(H) |
256(W)*128(H) |
320(W)*160(H) |
|
Module Resolution |
16*16 |
16*16 |
16*8 |
16*8 |
|
Scan Mode |
1/4 |
1/2 |
Static |
Static |
|
Brightness(cd/sqm) |
≥6500CD |
≥6500CD |
≥6500CD |
≥6000CD |
|
Power Consumption(max/avg)(W/pc) |
600/200 |
600/200 |
600/200 |
570/190 |
|
Gray Scale |
≥12bit≥14bit |
≥12bit≥16bit |
≥14bit |
≥14bit |
|
Unit Weight |
58±1 Kg/m² |
|
Contrast |
≥2000:1 |
|
Refresh Frequency |
≥800Hz |
|
View Angle |
H120°/V90° |
|
Gray Scale |
≥12bit |
|
Life Span |
50,000H |
|
MTBF |
5000H |
|
Ip Level(front/rear) |
IP65/IP54 |
|
Control System |
NOVA/DBSTAR/LINSN |
|
Working Temperature |
-30°C - +50°C |
|
Operating Humidity |
10-90% RH |
