Model No.:
P10 Outdoor Surface Mounted LED Display
Module Resolution:
32dots(W)*16dots(H)
Max Power Consumption:
20W
Module Thickness:
25cm
Module Weight:
0.5kg
Interface Way:
Hub75
Brightness:
5000CD/M2;
Cabinest Size:
960mm*960mm
Optinal Viewing Distance:
10m-50m
Average Power:
400W/H
Tube Chip Color:
Full Color
IP Rating:
IP67
Pixel Pitch:
10mm
Pixel Configuration:
1R, 1G, 1B
Display Function:
Video Display
Pixel Density:
10000 dot / m²
Scanning Mode:
1/4 Scan
Display Type:
LED Video Display
Application:
Advertising
Certification:
FCC/EMC
Average Power Consumption:
400W/H
Product Description
Our products: We specialize in producing and developing all kinds of led displays. As a reliable LED Display manufacturer and exporter in China, we supply Indoor led displays, Outdoor led displays, semi-outdoor led displays.Please kindly tell me which kind of the item you prefer to and provide me more information. It will help us to give you a good price.
Our features and advantages: 1.High quality: Use high quality LED with high luminous efficiency and low brightness decay to make the display stable.
2.Good effect: To show vivid and clear pictures with high resolution, but low cost; Has good display effect in both pictures and letters because of using real pixel technology.The products support multiple display modes.
3.Easy maintenance: Can fix the single point to save the maintenance cost.
4.Good uniformity: Brightness difference within 10% between any two LEDs, to ensure the brightness and color uniformity of the display; Good uniformity in color solve the problem of mosaic well
5.Price No. 1 cost effective. The price is very good, please contact us for an offer. You can compare and know!
6.Application It's wide Application, such as stage rental events, exhibition, wedding, advertising, meeting room and so on.
FAQ: 1. Are you manufacturer? If yes, in which city? Yes, we are the professional manufacture of LED display, and we work on it more than 10 years. Our company in Shenzhen, Dongguang, China.
2. Can I visit your factory ? We warmly welcome customers visit us. Before you come here, please kindly tell me your schedule, we can arrange for you. The nearest airport is Bao'an Shenzheninternational airport. 3. How about your quality warranty? 2 years quality warranty and lifetime technology support and maintenance from the second year. If you improperly operate or something wrong with our products, we are responsible for the maintaining and repairs instruction or guide free of charge.
Remarks 1.Payment term: 30% T/T in advance and balance before delivery.
2.Delivery time: Within 15 working days after 30% advance payment.
3.Free training: You can send your engineers who have knowledge of electronics and information to our factory and we provide free technical training, which contains training operation and maintenance of the LED display at our factory. We also offer the instruction manual, software, test report, drawing steel structure and so on.
4.Installation: We offer you the engineer to install the LED display, you have to offer him the two-way air tickets and accommodation as well as visa. The engineer's salary is $80/day;or we offer you the training on the LED display installation and repairing for free after you live in our company, or we can guide you to install the screen by remote control.
5. After service sales: If you have any questions about our product, you can inform us by mail or call, and we will reply you in 24 hours when we get you E-mail or call, and offer you a good solution for your problem.
Parameters of the unit module
Item
Parameter
Product model
P10 outdoor surface mounted LED Module
Module size
320mm*160mm
Pixel pitch
10mm
Pixel density
10000CD/m2
Pixel configuration
1R1G1B
Module resolution
32dots(W)*16dots(H)
Maximum power consumption
25W
Module thickness
25CM
Module weight
0.5kg
Driving method
Constant Current Driving
Scan mode
1/4scan
Interface type
HUB75
Brightness
≥5000CD/m2
Parameters of the cabinet
Cabinet size
960mm*960mm
Module quantity
18PCS
Power supply
5V/40A 5V/60A
Cabinet resolution
96*96dots
Optimal viewing distance
10m~50m
Optimal viewing angle
160°(W) 120°(H)
RH Working temperature
Storage:-35°C~+85°C
Working:-20°C~+50°C
System operating humility
10%-95%
Power
Operating voltage
AC220V±10%
Average power consumption
400W/H
Maximum power consumption
≤600W/m²
Current
≤20mA(single LED)
Control system
Computer
Pentium4 or above p4 or above
Operating system
WIN98/2000/NT/XP
Control model
Synchronization with PC
Main technical parameter
Driving device
IC Constant Current Driving
Refresh rate
≥600Hz
Grey scale
RGB Each 256 grade,,can display 16.7 M color
MTBF
≥9000hours
Power switch
Automatic Switch
Display mode
800*600/1024*768/1280*900
Our company supplies different kinds of products. High quality and favorable price. We're pleased to get your Inquiry and we will come back to as soon as possible. We stick to the principle of "quality first, service first, continuous improvement and innovation to meet the customers" for the management and "zero defect, zero complaints" as the quality objective.
?
