| Price: | US $ 500-700/Square Meter |
|---|---|
| Trade Terms: | FOB,CFR,CIF |
| Min Order: | 1/Square Meter |
| Pay Type: | T/T,D/P,Paypal,Money Gram,Western Union |
| Prod Model: | FOD-P10 |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Product Name: | Outdoor Full Color P10 LED Display for Advertising |
| Module Size: | 160mm*160mm |
| IC: | Mbi5024 |
| LED Chip: | Epistar |
| Brightness: | 6000CD/Sq.M-8000CD/Sq.M |
| Cabinet Size: | 960mm*960mm |
| Cabinet Material: | Iron/Aluminum/Rental Cabinet |
| Weight: | 50kg/Sq.M |
| Function: | Video/Graphic/Text |
| IP Grade: | IP65 Front/IP54 Back |
| Tube Chip Color: | Full Color |
| IP Rating: | IP65 |
| Pixel Pitch: | 10mm |
| Pixel Configuration: | 1R, 1G, 1B |
| Display Function: | Video Display |
| Average Power Consumption: | 600W / m² |
| Pixel Density: | 10000 dot / m² |
| Scanning Mode: | 1/4 Scan |
| Display Type: | LED Video Display |
| Application: | Advertising |
| Certification: | CCC |
Pixel pitch | 10mm |
Module size | 160*160mm |
Module density | 10,000dots/sqm |
Module resolution | 16*16 |
Pixel configuration | 1R1G1B |
Red wavelength | Epistar taiwan 625±2nm |
Green wavelength | Epistar taiwan 525±2nm |
Blue wavelength | Epistar taiwan 470±2nm |
Best viewing distance | From 10 to 150 |
Horizontal viewing angle | 110° |
Vertical viewing angle | 90° |
Maximum power consumption | Below 800W |
Brightness | 7500cd/sqm |
Gray scale | More than 4096 |
Control method | Synchronization |
Driving method | 4Sconstant current |
Frame frequency | 60Hz |
Refresh frequency | More than 300 Hz |
Working voltage | AC220V±5% |
IP grade | IP65 |
Working temperature | -20°C±50°C |
MTBF | More than 5,000 hours |
Life span | More than 100,000hours |
Cabinet style | Waterproof cabinet |
Cabinet size | W640*H640*D120mm |
Cabinet weight | Less than 28kgs |
