Display:
Touching-LCD Display
Ballast:
Electronic Ballast
Color System:
Cmy+6 Colors + Open
Gobo:
14 Fixed Gobos + 8 Rotating Viper Gobo + Open
Lamp:
Philips UHP 15r
Lens:
Yilong Glass Lenses
Spot Moving Head Light:
Spot Moving Head Light
Material:
Aluminum Alloy
Emitting Color:
Changeable
Strobe:
Combined Type Double Strobe
Control Mode:
Dmx Signal Control
IP Rating:
IP20
Certification:
RoHS
Light Source:
Philips UHP 15r
Control Channel:
21/23/34 Channels
Voltage:
100~240
Product Description
Martin New Viper Spot Moving Head Light
Youtube Demo: https://youtu.be/EkwBvKV1Xew
GOBOS 3-PRISM
CMY
Brighter: (New 330W Lamp Source Brings Incomparable Pure Brightness) Small size but stronger: (Comparable Output Of 1500W Fixtures,but 1/5 Power Consumption and 1/3 size Only 23kg, 41*37*75cm) Best color system: (CMY color mixing effect and 6 dichroic colors, YL optic system) Best gobo system: (2 gobo wheels: 14 static gobos and 8 rotating replaceable gobos) Most Funtional: (Zoom, Iris, Prism, Focus, Frost Filter, Shutter, with full Moving Heads Spot/Wash functions)
TECHNICAL PARAMETERS POWER SUPPLIE Input power:AC110-240V 50/60 Hz LAMP SOURCE Lamp: Yodn MSD R17 350W,1,500hr, 8000k(Optional Osram Siruis HRI 330W) Power Consumption: 350W OPTICS Lens: Anti-reflective coated lens YiLong optic system Output Lux: 10,500lux at 20 meters COLOR SYSTEM Colors: Basic color wheel with 6 dichroic mirrors, plus white, two direction rainbow effect. CMY Variable Color Mixing for Infinite Color Possibilities GOBO SYSTEM 8 rotating gobos plus open, all gobos can be easily replaceable and gobo indexing Static gobo wheel with 14 indexing gobos plus open, gobo shaking in different speed EFFECTS SECTION Prism and prism rotating , with 16 prism macros Linear dimmer in precise speed from 0% ~ 100% Stepless frost, 0%-100% linear change frost Motorized focus Iris from 5%~100% with pulse iris effect. Zoom: 9°~27° linear zoom Strobe/shutter: High speed shutter, 0-13 Hz or random strobe CONTROL AND PROGRAMMING DMX Channels: 3 DMX Modes-21/23/34 Channels DMX Control: 3-pin&5-pin DMX Control board with LCD graphic display BODY Remote controller lamp's switch function, display light and lamp's using time Structure: heat-proof plastic+module pressing alloy materials MOVING BODY Pan and tilt movement: 8 and 16 bit resolution For smooth and precise motion Movement: Pan: 360°/540°optional, Tilt: 270° Speed of pan/tilt movement adjustable Scan position memory, auto reposition after unexpected movement WEIGHT&SIZE Weight: 23kgs Dimensions: 409*419*541mm
Channel
Function
21 channel
23 channel
34 channel
CH1
CH1
CH1
Pan
CH2
CH2
Pan fine
CH2
CH3
CH3
Tilt
CH4
CH4
Tilt fine
CH3
CH5
CH5
Color wheel
CH6
Color wheel fine
CH4
CH6
CH7
Cyan
CH8
Cyan wheel fine
CH5
CH7
CH9
Magenta
CH10
Magenta wheel fine
CH6
CH8
CH11
Yellow
CH12
Yellow wheel fine
CH7
CH9
CH13
Rotating gobo wheel
CH8
CH10
CH14
Gobo wheel rotation
CH15
Gobo wheel fine
CH9
CH11
CH16
Fixed gobo wheel
CH17
Gobo wheel fine
CH10
CH12
CH18
Prism
CH11
CH13
CH19
Prism rotation
CH20
Prism fine
CH12
CH14
CH21
Focus
CH22
Focus fine
CH13
CH15
CH23
Zoom
CH24
Zoom fine
CH14
CH16
CH25
Strobe
CH15
CH17
CH26
Dimmer
CH27
Dimmer fine
CH16
CH18
CH28
Iris
CH29
Iris fine
CH17
CH19
CH30
Frost
CH18
CH20
CH31
Macro function speed
CH19
CH21
CH32
Pan/tilt speed
CH20
CH22
CH33
Macro function
CH21
CH23
CH34
Lamp on/off, reset
