IP Rating:
IP68
Emitting Color:
Blue
With Light Source:
With Light Source
Application:
Pond
Lamp Body Material:
Stainless Steel
Lampshade Material:
Stainless Steel
Style:
Modern simplism style
Base Type:
AR111
Technics:
Chrome-plating
Voltage:
24V
Certification:
RoHS
Product Description
WARNINGS!
LIGHTS ARE FORBOAT MANAGER BOARD USE ONLY!
AN UNDERWATER MARINE SEALANT REQUIRED AND 316 S/S screws to be used.
PROFESSIONAL INSTALLATION IS RECOMMENDED.
1 AMP FUSE MUST BE USED ON ALL POSITIVE CONNECTIONS.
WARRANTY WILL BE VOID IF FUSE NOT USED.
1 YEAR WARRANTY FROM DATE OF PURCHASE, REPAIR OR REPLACEMENT
VERIFY ALL DIMENSIONS BEFORE DRILLING ANY HOLES IN THE BOAT.
LIGHTS ARE ONLY ALLOWED TO CONNECT 12V/DC BATTERY.
Installation Instruction
Steps:
Mount the Stainless steel bracket to the trimtab making sure it is secure using marinegrade screws/nuts & bolts.
Run the wire up the Transom and enter the boat through an existing "Clam Shell" or drill a 3/16 inch holeabove the water line. Using a Sealant, seal the cable and use a "Clam Shell" to cover the wire.
Go inside the boat to the area where the wire comes through and seal the inside of the Transom withsealant as well.
Note: 1x9 & 2x9 LIGHTS you connect the (Red) Pos+ wire to a 12V switched/fused lead. You can usea 1amp fuse max. Hook up the Negative (Black) wire up to the negative battery terminal, makesure it hasgood connection.
Use the same wiring as per diagram for each light.
Light Connection Diagram
THE1*9W & 2*9W LIGHTS ARE ONLY ALLOWED TO CONNECT 12V/DC BATTERY.
