Product Description
LED street lamp: Green &enviromental, no light pollution; Energy-efficient; Long lifespan.
LED street lamp
1The Product Description
(1) High efficient AC or DC o. Peration system
(2) Integrated crust, , enhanced coolingsystem
(3) LED light source, , low light decay, high color rendering, long lifespan
(4)It is suitable for outdoor places such as expressways, urban roads, elevated roads, large flyovers, squares, and residential quarters, etc.
2 Technical Parameters
Items | Parameters |
Driving model number | GX-QD-45WAD |
Voltage rating of driven operation | AC 85~ 265 V |
Driving power | 45W |
Power factor | 92% |
Driving frequency | 50 |
Driving output voltage | DC 13~15V |
Drivng output current | DC CC2800MA± 100 |
LED Light decay | 10%5,000hours |
LED Power dissipation | 40W |
System power dissipation | 43W |
Initial luminous flux | 2800lm ( Tj= 25 ) |
Maintained luminous flux | 2400lmTj= 53 |
Valid light flux | 2200 lm ( Tj= 53 ) |
Luminous efficiency ( %) | > 85 % |
Install 6 meters average illumination ( E ) | > 22 lux ( @6meters ) |
Color temperature | 5000~ 7000 K |
Color rendering index (Ra) | > 75 |
Light source | 20WX2LEDmodule |
Light type curve | Oval |
Junction temperature ( Tj ) | 55 ± 1 ( Ta= 25 ) |
System thermoresistance (Rja ) | 0.45 / W |
Working temperature (Ambient temperature) | - 40 ~55 |
Working humidity(Relative humidity) | 10 % ~ 90 % RH |
Storage temperature | 10 ~85 |
Useful life | > 30,000 Hrs |
Shell material | Die-cast Aluminum |
Dimension (mm) | 620(L) X 300 (W) X160(H) |
Net weight | 8.0kg |
Protection grade | IP 55 |
Parameter from 6 metres highland light | 35mX12m |
Our company specialize in the production and trade of LED for many years. Our products mainly cover LED component, LED complete sets, which all CE and RoHS cetification, all clients from homeland or overseas shall choose and buy securely.
