Voltage / frequency: 90V-240V/50-60Hz
Bulbs: LED 1W/3W/5W (30 Red / 30 Green / 30 Blue / 30 White) (Or 40Red40Green40Blue)
Control signal: DMX 512, in sets at the automatic procedure
Channel: 13CH(RGBW/RGBA)/12CH(RGB), DMX512 channel control
Adjusts the light: 0-100 electron adjusts the light, various colors may alone move also may mix the color tone
Strobe: 1-25/second high speed strobe, but single color mixes the color strobe
Low power consumption
Super luminance, with the efficiency of ordinary power bulbs, rich and splendid color
DMX-512 control signal, 12 standard channels
The housing is made of streamline fashionable PC engineering plastic after once casting
Wide range super tiny smooth scanning, horizontal scanning angle reaches 450° And vertical 270° , the scanning precision reaches 8bit and 16bit, with smooth and precise positioning, additionally, the scanning speed is adjustable
Infinite RGB color mixed system
The light beam angle would choose from 6° - 60°
High speed electronic strobe reaches 1-18 times/second
Total light adjustment control channel can control 3 main color channels simultaneously
The digital display on the control panel can be reversed for 180° , applicable for horizontal or vertical use of moving head
With the functions of synchrony movement and music control
Meet CE standard, UL standard and GB7000.15-2000 standard.
DMX 13CH:
CH1: X adjusting
CH2: Y adjusting
CH 3: Strobe/ Reset/ Shutter
CH 4: Dimmer
CH 5: Color
CH 6: RED color change
CH 7: GREEN color change
CH 8: BLUE color change
CH 9: White color change
CH 10: RGB Rainbow Effect
CH11: X Fine
CH12: Y Fine
CH13: X/Y speed, Vector
