Battery:
100ah, 12V
Controller:
10ah,12V
Pole Height:
5m-10m
Light Source:
LED Light
Lamp Power:
30W
Color Temperature(',CCT):
Cool White
Power Supply:
Solar
IP Rating:
IP65
Lamp Body Material:
Aluminum Alloy
Application:
Garden
Certification:
FCC
Voltage:
12V
Average Life:
>80000h
Product Description
Solar Light Summary No cable trenching-significant cost savings No power bills Reduced pollution Reduced greenhouse gases (CO2) Range of low energy luminaires Single or twin LED lamps from 30W to 80W Low maintenance Standard Heights from 5m to 10m Custom colour finishes Designed for location
Work Principle The solar energy is converted into electricity stored in the battery by the solar panel through the day time, the solar panel voltage will decrease gradually in the dark time. When the voltage is lower than stipulated voltage, the controller will make the battery supply electricity to load; when the day become bright, the solar panel voltage increase gradually. After the voltage is larger than stipulated voltage, the controller will stop the battery supplying the electricity to load.
Item
Specification
Mono Solar Panel
1. 36pcs of mono solar cells 2. 105W/12V 3. Size(L×W×H): 801×1074×35 mm 4. Warranty:5 years
Gel Battery
1. 100AH/12V, maintenance free 2. Size(L×W×H): 412×173×233 mm 3. About Weight: 32kg±0.5 4. Design Life Span: 5-7 years 5. Warranty: 3 years
Pole, Panel Bracket, Base Flange, Underground Fittings, and Nuts
1. Hot dipped zinc galvanization + spraying powder coated 2. Material: Q235 steel 3. Pole Height: 6 m 4. Pole Thickness:3.00 mm 5. Flange size: 280*280*14 mm
Wire
1. One spool 2. Length of each spool: 13 m
