| Prod Model: |
H-0303LP**B |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Frame Color: |
Silver/White/Black |
| LED Type: |
SMD3528 |
| LED Driver: |
Meanwell |
| Light Source: |
LED |
| Appearance: |
Square |
| Type: |
Ceiling |
| Emitting Color: |
White |
| Certification: |
VDE |
| Housing Material: |
Acrylic |
| Voltage: |
85V-265V |
| Dimmable: |
With Dimmable |
| Base Material: |
Aluminium Alloy |
| Beam Angle: |
120 |
Product Description
Features:
Good quality Al6063 frmae dissipates heat efficiently
High-performance light guilde helps to proudce uniform light
No start-up delay, no flicking,no humming
CE,RoHS and UL certificated
Three installation methods:recessed,suspended and surface mounted
Available in three frame colors:silver ,white and black.
Available in there color temperatures:warm white,natural white and cool white
5 years warranty
Application:
School, supermarket, office,factory,conference roon, gym, billboard and etc.
Item/Model | H-S300LP**B | H-030060LP**B | H-S600LP**B | H-030120LP**B | H-060120LP**B |
| Size(mm) | 300x300x11.8mm | 300x600x11.8mm | 600x600x11.8mm | 300x1200x11.8mm | 300x1200x11.8mm |
| Power(W) | 18W/36W | 24W/32W | 36W/65W/72W | 36W/65W/72W | 65W/72W |
| Input voltage(V) | AC85-265V | AC85-265V | AC85-265V | AC85-265V | AC85-265V |
| Work voltage(V) | DC24 | DC24 | DC24 | DC24 | DC24 |
| LED Type | SMD3528 | SMD3528 | SMD3528 | SMD3528 | SMD3528 |
| LED QTY | 180/372pcs | 252/288pcs | 372/768pcs | 372/768pcs | 768pcs |
| Luminous Flux(LM) | 1224/2448lm | 1632/2176lm | 2448/4420/4680LM | 2448/4420/4680LM | 2448/4420/4680LM |
| Color Temperature(K) | 2800-6500k | 2800-6500k | 2800-6500k | 2800-6500k | 2800-6500k |
| CRI | >70/80 | >70/80 | >70/80 | >70/80 | >70/80 |
| Illumination | Edge-lit | Edge-lit | Edge-lit | Edge-lit | Edge-lit |
