| Prod Model: |
YC-6024 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| LED: |
3W X 24 RGB 3 in 1 |
| Light Length: |
1 Meter |
| Working Tempreture: |
-20-45 |
| Power: |
80W |
| Warranty: |
1 Year |
| IP Rating: |
IP65 |
| Certification: |
RoHS |
| Lifespan: |
50000 hours |
| Electric Current Type: |
AC |
| Beam Angle: |
15,25,35,45 Degree for Selectable |
| Input Voltage: |
90-250V/ 50~60Hz |
| Emitting Color: |
RGB 3 in 1 |
Product Description
Led dmx bar outdoor wall washer 3W 24 RGB 3 in 1
Voltage: 90V-240V AC Or 12V/24V DC
Protect rating: IP65
Beam of light angle: 45° 25° 60°
Source Light: 3W x36 LEDs
Life time: 50000hours
Display board: Digital display
Cover material: Aluminium
Condition temperature: -18C° ~45C°
Control mode: DMX-512
Adopting high-power LED as light source. Energy-saving, environment protecting.
Using constant current to drive.
Low working voltage, secure and reliable.
Low power consumption, good color saturation. Energy sawing up to 80%.
Packing Dimension: 130*32*32cm(4pc/CTN)
Gross weight: 6KG / unit
|
Operating Voltage |
AC 90-240, 50/60 Hz |
|
Power |
80W |
|
Light source |
24pcs x 3W RGB 3 in 1 LED, 100, 000 hours, Flicker free for television and film |
|
Color |
RGB 3 in 1 color, can be mixed to more than 16.7million kinds of color |
|
IP Rated |
IP 65 |
|
Beam angle |
1 5° , 25° , 35° , 45° ( optional ) |
|
Luminous Intensity |
14, 000 Lux @ 1m |
|
Insulation Resistance |
> 2MΩ |
|
DMX channel |
7 DMX channels |
|
DMX model |
DMX512, Master/slave, auto-running |
|
DMX signal |
Input/Output: 3-pin XLR |
|
Control pannel |
2-button control panel |
|
Strobe |
0-30Hz/Second |
|
Dimmer |
0-100% linear adjustment |
|
Structure |
Aluminum chassis, high quality cooling system |
|
Warranty |
1-year limited warranty, does not cover malfunction caused by damage |
|
G. W |
6 kgs/ piece |
|
Dimensions(LxWxH) |
1200 x320 x320mm (4pcs/CTN) |
Guangzhou Zenith Aurora Lighting Co., Ltd. is very specialize in designing and manufacturing lighting equipment, since year 2000. With over 10 years experience and strict ISO approved standards, we assure worldwide customers of high quality products and offering the best service from replying inquiry to shipment arrangement. Excellent service is satisfy all of our customer and built up a very nice business-ship with some well know brands.
MAIN PRODUCT
LED outdoor &indoor light, LED Street light. Stage move head, Outdoor search light., follow spot light, stage effect light.
RESEARCH & DEVELOPMENT
Our R&D team is always researching what will be the most popular products for future market demand and provide a total solution for products development, this concept lead San Yeah Lighting International toward a very certain picture for its aggressive future. Our R&D team integrates all steps at factory from products concept, mechanical construction design, organization design to model development. Taking this advantage, we offer the most competitive products to worldwide customers.
