North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Tube Chip Color:
Full Color
IP Rating:
IP65
Pixel Pitch:
16mm
Pixel Configuration:
2R, 1G, 1B
Display Function:
Video Display
Average Power Consumption:
350W / m²
Pixel Density:
1024 dot / m²
Scanning Mode:
1/4 Scan
Certification:
ETL
Product Description
Features of the product: 1) High brightness and be adjustable, meets the need of the changing requirement of customer in environment. 2) Having good lightening accordance and no mosaic. 3) Using virtual pixels, better viewing effect for both text & graphic and video. 4) Having larger viewing angle: Horizontal angle 100 degree / elevation angle 45 degree. Getting vivid effect within any position of the viewing range. 5) Any LED in each pixel can be respectively repaired, which reduce the cost of the display maitenance. 6) Good heat emission capability 7) Environmental-friendly.
pH25 LED Display Screen/LED Screen/outdoor LED Display Num Item Specifications
1 Pixel pitch 25mm 2 Density of pixel 1600/m2
3 Color constitution 2R, 1G, 1B
4 Cabinet resolution 40dots*40dots
5 Driving Method Constant static
6 Optimal Viewing Distance 19-200m
7 Ingress Protection(front/back) IP65/IP54
8 Operating Humility 10% ~ 90% RH
9 Operating Temperature -20° C ~ +60° C
10 Optimal Viewing Distance 19m-200m
11 Average Power Consumption 180W/m2
12 Gray Scale 16384 grade
13 Brightness Control 256 grade
14 Frame Frequency 60Hz
15 Refresh Speed >300Hz
16 Power Supply 220V/50Hz
17 MTBF ≥ 10000hours
18 Life Span (50% brightness) ≥ 100, 000hours
19 Control Mode Synchronization with PC
20 System Operating Platforms WINDOWS(98/2000/XP/Vista)
21 Input Signal Format VGA, DVI, RGBHV, Composite, S-Video, TV
22 Module Size (W * H) 125mm*250mm
23 Cabinet Size (W * H) 1000mm*1000mm
24 Display Color 1, 070, 000, 000
We are the leading OEM manufactures of LED Display Screens in China, which is professionally engaged in the production of Indoor, Outdoor and Semi-Outdoor LED Display screens in Single, Bi-color and Multi color for different markets such as Malls and Plazas, Traffic guiding signs, Entertainment and Stage, Shop sign boards and huge Media Bill Boards, Security Monitors etc. We are an ISO 9001: 2000 company, CE certified, RoHS certified, export licence holders.
Shenzhen Mary Photoelectricity Co., Ltd (MRLED) is a subsidiary of state-owned listed company-- Fujian FURI Electronics Co., Ltd. And was established in 2006 April, which the registered capital is 100 Million RMB. MRLED is a national level and high & new technology enterprise which specialize in designing, researching, manufacturing and selling all kinds of LED displays.
Experienced nine years of development, nowadays MRLED own its factory workshop area about 30, 000sqm, monthly capacity is 8000sqm, the number of employees more than 800. Company has the international first-class technology development talents and advanced production equipment, a comprehensive standardized management, product technology and quality is in the forefront between the similar products in domestic market. Also enjoy good reputation in the global market.
MR LED' products widely used in outdoor advertising, cultural and recreational activity, stadium, stage background rental, With its full color LED displays advantages, from the design, productions, installation to the maintenance, Use of comprehensive integration solutions, effectively reduce the overall cost for customers, so as to create more value for customers.
In past 8 years, MRLED service team almost traveled in all over the world, always uphold the core values of "Professional, Team, Integrity, Effectiveness, Communication", provide professional, caring, attentive after-sales service for global customers. Nowadays, MRLED's products selling to over 400 cities in autonomous regions and 34 provinces in China by virtue of high reliability and cost performance, earned thousands of customers, and also had built long term business relationship with the more than 90 countries' customers, like in USA, Germany, Spain, Portugal, Thailand, Korea, Poland, Italy etc. MRLED with its reliable quality, excellent service and good faith strives for realism style, won the user's high praise from all walks of life. No matter what's the major events & Competition venues in domestic and overseas, which like in the Guangzhou Asian games, the Shanghai world expo, each big TV station in domestic, railway stations, world beach volleyball tour, and Sydney autodrome, etc. All of them have a figure of MRLED.
