Working Temperature:
-40 - +50
Power Factor:
0.98
Frequency:
50Hz / 60Hz
Dimension:
900*315*100mm
Type:
Floodlight
Space Height Ratio:
3
Working Lifetime(Hour):
100000
Power Supply:
AC
Color Temperature:
Cool White
Lamp Body Material:
Aluminum Alloy
IP Rating:
IP66
Certification:
RoHS
With Light Source:
With Light Source
LED Chips Brand:
CREE
Power:
150W
Application:
Industrial Light
Input Voltage:
90-305VAC
Product Description
IP67 waterproof dustproof led street light from china
Application
This product is widely used in the factory,various city road,high ways as street light.
Characteristics
1.Out of consideration of the difficulty of road lighting replacement, the company developed a unique cooling system modules, an effective solution to the problem of LED light failure caused due to high temperature to ensure high efficiency light source with 100,000 hours of life. 2.The even light distribution can avoid the shadow area between the two streetlights. It is glare free. And has a pure white light. 3.It adopts American CREE LED as light source, can save 60% or more on energy than the metal halide lamp. 4.Equipped world top ranking brand, Taiwan Meanwell electrical appliance with power factor 0.98, make the lamp's performance more stable and efficient. 5.Specially designed light lid, easy maintenance. 6.The shell adopts high-tech surface spraying technology, abrasion resistance and resistance to corrosion, waterproof, dustproof, applicable to all kinds of environment. 7.Mounting: suitable to pole with the diameter of Φ50-Φ60mm
Main specification
Input Voltage
90-305VAC
Frequency
50Hz / 60Hz
Ingress Protection
IP65
Anti Corrosion Grade
WF2
Insulation Grade
I
Space Height Ratio
3
Ordering reference
Ordering Reference
Light Source
Rated wattage (W)
Light output (lm)
Dimension (mm)
Net Weight (Kg)
Average Service Life (h)
ZY8702-L50
LED
50
>100 lm / W
425×315×100
5.5
10,000
ZY8702-L60
LED
60
520×315×100
6.5
10,000
ZY8702-L80
LED
80
520×315×100
6.5
10,000
ZY8702-L100
LED
100
520×315×100
6.5
10,000
ZY8702-L120
LED
120
615×315×100
7.5
10,000
ZY8702-L150
LED
150
615×315×100
7.5
10,000
ZY8702-L180
LED
180
710×315×100
8.5
10,000
ZY8702-L200
LED
200
710×315×100
8.5
10,000
ZY8702-L250
LED
250
805×315×100
9.5
10,000
ZY8702-L300
LED
300
900×315×100
10.5
10,000
