Prod Model: |
AirLED-3 |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Unit Size: |
500x500x65mm |
SMD: |
3-in-1 Black Body SMD |
Unit Weight: |
7kg |
Contrast Ratio: |
4000: 1 |
Tube Chip Color: |
Full Color |
Display Function: |
Video Display |
Scanning Mode: |
1/16 Scan |
Application: |
Shopping Guide |
Certification: |
RoHS |
System Operating Platform: |
WIN XP |
Pixel Configuration: |
SMD 3-in-1 |
Pixel Pitch: |
3.9mm |
IP Rating: |
for Indoor Use |
Pixel Density: |
65,536 Dots/Sqm |
Product Description
CreateLED indoor AirLED-3 series have robust precision extruded aluminum section and contrast ration comprised for both rental and permanent installations. Totally black body and revolutionary black body LEDs makes the display delivers the deepest black level in the market, and the highest attractive contrast ratio of over 4000: 1.
Main feature:
1. Ultra-light weight and slim design
2. Fanless design and front maintenance
3. Quick lock system allowing handling fast
4. Standard panel size 500mmx500mm making flexible assembling and dismantling
5. Higher contrast ratio with true black body SMD available
6. High refresh rate available for capture for DV&VCR
Model |
AirLED-3 |
Pixel Pitch |
3.9mm |
Unit Size |
500mmx500mmx65mm |
LED Type |
SMD 3-IN-1(black body) |
Pixel / Unit |
128x128 |
Unit Weight |
7kg |
Viewing Angle |
H160 degree V100 degree |
Application |
Storage-40~60° C, Working-20~50° C |
Protection Level |
For indoor use only |
Power Consumption |
200W/panel Max |
80W/Panel Ave. |
Driving |
1/16 Scan |
Frame Refresh |
≥ 60Hz |
Data Refresh Rate |
600~2, 000Hz |
Processing |
16bit |
Max Brightness |
1, 500nits |
Power Supply |
AC90-240V, 50~60Hz |
MTBF |
≥ 1, 000 Hours |
Life Span |
≥ 50, 000 Hours |
Pixel Failure |
< 0.0003 |
Shenzhen CreateLED Electronics Co, . Ltd. Is one of the most professional LED Screen manufacturer to provide full solutions for fixed billboard market and rental market.
Especially since year of 2010 we explored and issued the innovative newly AirLED series for rental customers, standard solution for different applications, standard solution for ourselves mass production.
About outdoor fixed installation billboard, we are promoting the full viewing angle, complete water proof and lower power drive method outdoor cabinets, which is leading the trend of this billboard market.
Welcome to our Showroom and My Products for more detailed offer info.
