| Prod Model: |
P10 Outdoor Full-color LED Display |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Module Size: |
160X160mm |
| Cabinet Size: |
960X960mm |
| Optimal Viewing Angle: |
160°(W) 120°(H) |
| Cabinet Resolution: |
96X96dots |
| Working Voltage: |
220VAC |
| Control Mode: |
Synchronization with PC |
| Optimal Viewing Distance: |
10m~50m |
| Refresh Rate: |
1200Hz |
| Module Thickness: |
25mm |
| Mtbf: |
>9000hours |
| Tube Chip Color: |
Full Color |
| IP Rating: |
IP65 |
| Pixel Pitch: |
10mm |
| Display Function: |
Video Display |
| Average Power Consumption: |
350W / m² |
| Scanning Mode: |
1/4 Scan |
| Display Type: |
LED Video Display |
| Application: |
Advertising |
| Certification: |
EMC |
| Pixel Density: |
27777dots/M2 |
Product Description
Why choose our LED display?
1.Experience advantage:more than 10 years manufacturing experience,powerful factory!
2.Price advantage: Factory Outlet,No.1 cost effective
3.Quality advantage: superior LED led lamp from our own factory,serious QC control system,best materialr(passed ISO 9001,CE,RoHS,IP65 waterproof certification...)| Item | Parameter |
| The specifications of led display module |
| Product model | Outdoor P10 full color module |
| Module size | 160mm*160mm |
| Pixel pitch | 10mm |
| Pixel density | 10000dots/m2 |
| Pixel configuration | 1R1G1B |
| Module resolution | 16dots(W)*16dots(H) |
| Maximum power consumption | 20W |
| Module thickness | 2.5cm |
| Module weight | 0.5kg |
| Driving method | Constant current driving |
| Scan mode | 1/4 scan |
| Interface type | HUB75 |
| Brightness | ≥7500cd/m2(can be customized) |
| The specifications of led display cabinet |
| Cabinet size | 960mm*960mm(can be customized) |
| Module quantity | 36pcs |
| Power supply | 5V/40A 5V/60A |
| Cabinet resolution | 96*96dots |
| Optimal viewing distance | 10m~50m |
| Optimal viewing angle | 160°(W) 120°(H) |
| Temperature | Storage:-35ºC~+85ºC/Working:-20ºC~+50ºC |
| System operating humility | 10% - 95% |
| The specifications of led display power supply |
| Operating voltage | AC 110V / 220V±10% |
| Average power consumption | 350W/H |
| Maximum power consumption | ≤700W/ |
| Current | ≤20mA(single LED) |
| The specifications of led display control system |
| Computer | Pentium4 or above |
| Operating system | WIN98/2000/NT/XP |
| Control model | Synchronization control |
| The specifications of the led display main technical parameters |
| Driving device | Constant current driving |
| Refresh rate | ≥600Hz |
| Grey scale | RGB each 256 grade, can display 16.7M colors) |
| MTBF | ≥10000hours |
| Power switch | Automatic switch |
| Display mode | 800*600/1024*768/1280*900
|
1.Payment term: 30% T/T in advance and balance before delivery.
2.Delivery time: 10-15 working days after 30% advance payment.
3.Quality warranty: Two years quality warranty and lifetime technology support and maintenance from the second year. If you improperly operate or something wrong with our products, we are responsible for the maintaining and repairs instruction or guide free of charge.
4.Free training: You can send your engineers who have knowledge of electronics and information to our factory and we provide free technical training, which contains training operation and maintenance of the LED display at our factory. We also offer the instruction manual, software, test report, drawing steel structure and so on.
5.Installation: We offer you the engineer to install the LED display, you have to offer him the two-way air tickets and accommodation as well as visa. The engineer's salary is $80/day;or we offer you the training on the LED display installation and repairing for free after you live in our company, or we can guide you to install the screen by remote control.
6.Service after sales: If you have any questions about our product, you can inform us by mail or call, and we will reply you in 24 hours when we get you E-mail or call, and offer you a good solution for your problem.
7. Packaging
We provide plywood wooden box packaging and Air box packaging.Customers can freely choose box and packaging way.But in any case, we will both ensure the use of appropriate packaging to protect the safety of the goods.
8. Transportation
Customers can freely choose box also the shipping way, by air, by sea or by train. We have professional freight forwarders, on the transportation we will not earn customers one penny of profit. Of course customers also could use your own freight forwarders, we will to fully cooperate with you.
Our company supplies different kinds of products. High quality and favorable price. We're pleased to get your Inquiry and we will come back to as soon as possible. We stick to the principle of "quality first, service first, continuous improvement and innovation to meet the customers" for the management and "zero defect, zero complaints" as the quality objective.
