North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Display Type:
LED Video Display
Tube Chip Color:
Full Color
Display Function:
Video Display
Certification:
ETL
Pixel Pitch:
6mm
Pixel Density:
27,777 dots / m²
Application:
Shopping Guide
System Operating Platform:
WIN XP
Scanning Mode:
1/16
Pixel Configuration:
3in1 SMD
IP Rating:
IP31
Product Description
Features: The design has the features of "light","thin", "fine", "penetrate ". Convenient installation, withstand wind and dustproof. Application for the stage and surrounding.
This product has been applicated at many fields such as stage, bar, entertainment TV and so on, it has been shown the unique artistic charm and aesthetic feeling of space imagination.
The brightness can be adjusted from 500 nits to 2000 nits without damaging the gray level, matching with calibration technology, it has the great expressive color.
The product is with convenient installation, and flight connectors connecting. Now it has become the most popular fashion elements at the digital stage and bar.
High refresh frequency can meet the requirement of the shooting on the stage, presents the perfect effect.
Item
Indoor Fixed LED display Series
Pixel Pitch(mm)
3mm
4mm
5mm
6mm
Pixel density(pix/m2)
111111
62500
40000
27777
LED Type
2020
2020
3528
3528
Viewing Angle
H:140°,V:140°
Color Depth(nits)
1000
1200
1500
1500
Drive Method
1/32
1/16
1/16
1/16
Color Depth
16384
Refresh Rate(Hz)
1200
1200
1200
1200
Module Size(mm)
192×192×13
256×128×13
160×160×13
192×192×13
Cabinet Size(mm)
384×384
512×512×133
640×640×133
768×768×133
Cabinet Material
Aluminum
Iron Sheet Metal
Iron Sheet Metal
Iron Sheet Metal
Cabinet weight(kg)
9
15
23
32
Voltage
110/240V
Average.power(W/m2)
300
250
160
120
Max.power(W/m2)
900
750
480
350
IP Grade
IP31
Operating temperature/humidity
temperature:-20ºC~ 50ºC humidity:10~90%RH
Storage temperature/humidity
temperature:-40ºC~ 60ºC humidity:10~90%RH
Lifetime(h)
≥50000
Compliant Standard
CE,FCC,RoHS,ETL,CCC
