IP Grade:
IP60
Module Size:
192*96
Color:
1r1g1b
Scanning:
1/16 Or1/8
Warranty:
3-5 Years
Life Span:
>100,000hours
Mtbf:
10000hours
Working Voltage:
AC220V/110V±10% DC5V/12V
Refresh Frequency:
350Hz
Frame Frequency:
60Hz
Tube Chip Color:
Full Color
Display Function:
Video Display
Pixel Pitch:
6mm
Pixel Configuration:
1R,1G,1B
Pixel Density:
27,777 dots / m²
Scanning Mode:
1/8 Scan
System Operating Platform:
WIN XP
Display Type:
LED Video Display
Application:
Stage Performance
IP Rating:
IP60
Certification:
SGS
Product Description
Feature and Advantage 1. Waterproof:IP31 2. Best viewing distance: 6-150m 3. White balance brightness: 3000-4000CD/sqm 4. Horizontal viewing angle: 140degree 5. Working temperature: -30degree-+80degree 6. Life span: More than 100, 000hours 7. Contrast ratio: 4000: 1 8. Products consumption: 800W
Application and Market 1. Application Indoor advertising LED display widely use in shopping mall ,theater,clubs,bars,bank,hotel,restaurant,stadium,airport,bus station ,meeting room,wedding,subway,book store etc. 2. Market: North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, MID East, Eastern Asia, Western Europe
Description
Technical parameter
Unit module
Module size
384*192mm
Pixel pitch
6mm
Pixel density
27,777dots/m2
Pixel configuration
1R1G1B
Led specification
ellipse
Pixel resolution
W: 64dots*H: 32dots
Cabinet
Dimension
1152mm*960mm*130mm
Quantities of module
15pcs
Power supply
4pcs
Scan mode
1/32
Weight
45kg/m2
Best viewing angle
6-150m
Temperature
Storage: -35° C~+85° C
Working: -35° C~+85° C
Thickness
adjustable
Remarks: cabinet size can changed, upon project need.
Power
Working voltage
AC220V/110V± 10%
Average power consumption
400W
Max. Power consumption
≤ 800W/sqm
Current
≤ 20mA(single LED)
Control system
CPU
Pentium4 or above
Operating system
Windows2000/XP/Vista/Windows7
Control method
Synchronization & Asynchronization
Main technical parameter
signal input(Video processor)
AV,S-Video,VGA,DVI,HDMI,SDI,DP
Drive type
Constant Current driver IC
Refresh frequency
≥ 400Hz
Grey scale/colors
256 levels of each color(R/G/B)/16.7M color
Brightness of white balance
3000-4000cd/sqm
Brightness adjustment
256 levels of each color(R/G/B)by software
Operating ambient humidity
10%--95%
Video signal
PAL/NTSC
Control system
DVI display card+full color controller card
MTBF
≥ 10, 000hours
Life span
≥ 100, 000hours
Flatness
Tolerance of inter pixel ≤ 0.3mm
Tolerance of modules clearance≤ 0.6mm
Power switch
Automatic switch
Display mode
1024*768
Communication distance
Unshielded twisted pair net line transmission distance 100m, max transmission distance 200m. Multi-mode Optic fiber transmission distance 500m; Single-mode optic fiber transmission distance 10KM
Software
LED media player
Our service 1. Your inquiry related to our products or price will be replied in 24hrs 2. OEM, any your customized lightings we can help you to design and put into product 3. Distributorship are offered for your unique design and our current models 4. Protection of your sales area, ideas of design and all your private information
Trade Terms:
Payment terms:
35% deposit before production, 65% balance before shipping -T/T: -Paypal -Western Union -Escrow
Packing:
-Standard Export Carton with fully Polyfoam or Pearl Wool -Flight case; -Anti-shaking wooden case
Shipping:
LED module: 3 to 5 working days upon receiving deposit payment LED display: 5 to 8 working days upon receiving deposit payment
After-Sales-Service:
-Lifetime with professional engineer support. -Within 1 year, supply spare parts for free if the machine has quality problem
Our Company: FOXGOLDEN GROUP LTD (www.foxgolden.com)is a professional high quality LED display manufacturer. Since 2004, we have been dedicating to the aim that producing high quality products, and now FOXGOLDEN has been well integrated in terms of R&D, produce, project, capital and marketing.
On October 13th, 2015, FOXGOLDEN became official listed company at Shenzhen equity trading Center in Shenzhen. equity code is 666153, which is another promising take-off of FOXGOLDEN . At present, Foxgolden Group Limited has formed a series of LED display products: outdoor LED display, indoor LED display, Portable LED screen, Foldable LED screen, Soft LED screen rental LED display, stadium LED display, small pitch pixel LED display etc.. Till to 2015,We have 11-year production experience. We have 11-year design experience of offering solution, installation, and after-sales service, etc. Faced with a variety of requirements, we offer flexible diverse solutions. We offer 24-hour all-direction online service. We achieve customer complaint rate below 0.1% and win widespread high praise and good reputation from customers and public.
Package and shipping: 1.Anti-shocking wooden case: Usually use for cabinets. 2.Flight case:Usually use for cabinets 3.Carton box:Usually use for modules
Transportation: 1.By sea, 2.By air , 3.By express
FAQ Q1: When is the delivery time? A1: we will accomplish manufacturing within 10 days after receiving the deposit.
Q2: What is the payment method? A2: We support a variety of payment methods,the most common is the TT.
Q3: What's the pixel pitch for Outdoor LED Display Screen? A3: Outdoor (P6mm / P8mm/P10mm)
Q4: Where is it used for? A4: Outdoor & rental use. Widely used for backdrop of staging event, rental business, liveshow, concert, etc.
Q5: Can it play HD video? A5: Yes, it can realize HD video function with Linsn controlling system.
Q6: What's the controlling system? A6: Our standard controlling system for this model is Linsn, Novastar. Also support other controlling system, like Xixun,TF, Colorlight, etc.
Q7: How about the size of project? A7: Please offer the size with "width by height" of project. We will offer the suitable solution for your project size. I will appreciate it if any drawing files about installation offered.
Q8: How about your service? A8: 1. Lifetime free maintenance and upgrade. 2. Complaint respond period not exceed 24 hours; maintenance guidance and problem solution supplied in 48 hours. 3. Customer satisfaction tracking report. 4. Free technician training. 5. Full set of documents free of charge, which including installation guidance, software operation manual, easy maintenance manual and control system software CD and so on. 6. Special service for big project, such as stadium, exhibitions, squares and so on.
