| Prod Model: |
RUBIK-10 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Tube Chip Color: |
Full Color |
| Display Function: |
Video Display |
| Scanning Mode: |
1/8 Scan |
| Application: |
Stage Performance |
| Pixel Configuration: |
1R,1G,1B |
| Pixel Pitch: |
10mm |
| IP Rating: |
IP54 |
| Certification: |
CE |
| Pixel Density: |
10,000 dots / m² |
| System Operating Platform: |
WIN XP |
Product Description
Technical Parameters:
Resolution: 10mm pitch
Density: 10000 dots/SQ. M
Pixel: RGB 3-in-1 LED
Bit depth per color: 16 bit
Bit depth per pixel: 48 bit
Viewing angle: 120
Service life: 80, 000 hours
Brightness (white): 2050 nits
Brightness level: 16 levels
Fresh frequency: 60Hz
Innovation: ≥ 7000Hz
Drive mode: Constant current
Control mode: VGA synchronous display
Display mode: 1024× 768, 1280× 1024
Display port: DVI
Working voltage: 90~264VAC 50/60Hz
Power consumed: 65W/ SQ. M
Face material: Plastic+Metal
Weight: 9.0kg/ SQ. M
Weather rating: IP 44
Optimal visual distance: 6m
Ambient relative humidity: 10%~90%
Working temperature: -10 ~50
Package: Flight case optional
Recommendation Size: 320mm width x 1280mm height
Installation: Hang
Control system: Power-600, Power-1200
Safety certificate: CE, FCC
