| Prod Model: |
BL-PAR30-7Semi |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Warranty: |
3 Years |
| Life Span: |
50, 000 Hours |
| CRI: |
Ra80 |
| Power Factor: |
0.9 |
| Certificate: |
CE, RoHS |
| LED Chip: |
Semi, CREE Xr |
| Wattage: |
12.1W |
| Weight: |
300g |
| Dimension: |
95(Dia)X100(H) Mm |
| Beam Angle: |
8, 15, 25, 45, 60, 90, 120 Degree |
| Light Source: |
LED |
| Install Style: |
Desktop, Aisle, Showcase, Studyroom, Living Room |
| Color: |
Warm White or Cool White |
| Voltage: |
85~145V AC or 190~265V AC |
| Base: |
E27, E26, B22, B14 |
| Certification: |
CE&RoHS |
| Emitting Color: |
Warm White or Cool White |
Product Description
1) Color Temperature: Warm White: 2, 700 ~3, 500K, Cool White: 5, 000~6, 500K
2) Beam Angle: 8, 15, 30, 45, 60, 90 and 120 degrees
3) CRI: Ra> 80
4) Power Factor: >0.9
5) Dimmability: Compatible with TRIAC dimmers on market such as Lutron, Leviton, Legrand, Osram, and GE etc. Dimming range is from 5~100% and very stable
6) For each item, there is a lower price version with non dimmable and/or CREE XPC LED
7) Life Span: 50, 000 hours
8) Warranty: 2 years
9) Certification: CE, RoHS
10) Housing Color Option: Natural aluminum and anodized white or black
These series are for spotlights having been sold on market for years with stable quality, quick lead time and price competitive. \
Characteristic:
ITEM NUMBER: BL-PAR30-7SEMI
BULB TYPE: 7X1W & 7X2W & 7X3W PAR30 LED Bulb
LED CHIP Q'TY: 7PCS LED
BASE TYPE: E26/E27
LED TYPE: SemiLED
APPLICABLE DIMMERS: TRIAC DIMMER FOR LUTRON, LEVITON, LEGRAND, ORSAM, CE etc. INPUT VOLTAGE: 85~145V AC and 190~265V AC
DIMMING RANGE: 10%~100%
INPUT POWER: 7X1W: 8.7W
7X2W: 10W
7X3W: 12.1W"
OUTPUT POWER: 7X1W: 7W
7X2W: 8W
7X3W: 9.7W"
SIZE: 95(Dia) x 100mm
REFLECTOR EFFICIENCY: 90%
OUTPUT CURRENT: 7X1W: 320mA
7X2W: 340mA
7X3W: 350mA
LUMENS: Semi LED
7X1W WW: 420m, CW: 560m
7X2W WW: 510m, CW: 655lm
7X3W WW: 590lm, CW: 760lm
COLOR RANGE: 2, 700~7, 000K
BEAM ANGLE: 15, 30, 45, 60, 90, 120 degrees
LIFE SPAN: >50, 000 HOURS
BODY TEMPERATURE: <65° C
LED WORKING TEMPERATURE: <72° C
CRI: Ra> 80
NET WEIGHT: 250g
HOUSING MATERIAL: ALUMINIUM
NO UV OR IR RADIATION
CERTIFICATION: CE, RoHS, C-Tick
Package
Carton dimension 102x102x106mm, Pack size: 36 PCS
|
Item Number |
BL-PAR30-7Semi-DIM |
|
Voltage |
85~145V AC
190~265V AC |
|
Lumens |
WW: 590lm
CW: 760lm |
|
Dimmability |
YES |
|
Dimension |
diameter 95× 100mm |
|
Weight |
300g |
|
LED Type/ QTY |
CREE XRE/ Semi/ 7pcs |
|
Power Consumption |
12.1W |
